Philips MC-M570/21 - ELECTRICAL PARTSLIST 5 DTC MODULE MP3 CD Version CD Board; Mechanical Parts; Miscellaneous; Capacitors

MECHANICAL PARTS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3103 308 54710 5DTC Module (mechanic w/o electronic)
201 3103 309 05390 CD DRIVE DA12T3
252 4822 529 10387 Rubber damper CD DRIVE, FRONT
253 4822 529 10386 Rubber damper CD DRIVE, REAR
MISCELLANEOUS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3103 308 67020 MP3 Board
1800 4822 267 11028 FFC-CONNECTOR 16P, Side entry
1820 2422 025 17303 FFC-CONNECTOR 19P, Side entry
1823 2422 025 16371 FFC-CONNECTOR 8P, Side entry
1824 4822 265 10979 FFC-CONNECTOR, 15P, Side entry
8001 3103 308 93090 FFC CABLE 16Pin 80mm BD
8051 3103 308 93100 FFC-CABLE 19Pin 90mm AD
8052 3103 308 93120 FFC CABLE 8Pin 80mm BD
CAPACITORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
2812 4822 124 11947 10µF 20% 16V
2813 © 4822 126 13193 4,7nF 10% 63V
2814 © 5322 126 11579 3,3nF 10% 63V
2815 © 2020 552 94427 100pF 5% 50V
2816 © 3198 017 42230 22nF 10% 50V
2817 4822 124 22726 4,7µF 20% 35V
2818 © 3198 024 44730 47nF 5% 50V
2821 © 2238 586 59812 100nF 10% 50V
2822 © 4822 126 13344 1,5nF 5% 63V
2823 4822 124 42383 220µF 20% 4V
2824 © 4822 126 14043 1µF 20% 16V
2825 © 4822 126 13344 1,5nF 5% 63V
2826 © 3198 017 34730 47nF 10% 16V
2827 © 5322 126 11578 1nF 10% 63V
2828 © 4822 126 11669 27pF 10% 50V
2829 © 3198 017 34730 47nF 10% 16V
2830 4822 124 81286 47µF 20% 16V
2831 4822 124 81286 47µF 20% 16V
2832 © 3198 017 31530 15nF 10% 50V
2833 © 5322 126 11583 10nF 10% 63V
2834 © 3198 017 31530 15nF 10% 50V
2835 © 5322 126 11583 10nF 10% 63V
2836 4822 124 40433 47µF 20% 25V
2837 © 3198 017 34730 47nF 10% 16V
2838 © 3198 017 44740 470nF 20% 10V
2839 © 2238 586 59812 100nF 10% 50V
2840 © 4822 126 14549 33nF 10% 16V
2841 © 2238 586 59812 100nF 10% 50V
2843 © 2020 552 94427 100pF 5% 50V
2844 © 5322 122 33861 120pF 5% NP0
2845 © 5322 122 33861 120pF 5% NP0
2846 4822 124 40248 10µF 20% 63V
2847 © 3198 017 41050 1µF 20% 10V
2848 © 2020 552 94427 100pF 5% 50V
2849 © 5322 122 33861 120pF 5% NP0
2850 © 5322 122 33861 120pF 5% NP0
2851 4822 124 40248 10µF 20% 63V
2852 © 4822 126 14549 33nF 10% 16V
2853 © 5322 126 11583 10nF 10% 63V
2854 4822 124 12245 220µF 20% 16V
2855 4822 124 11912 220µF 20% 6,3V
2860 © 4822 122 33753 150pF 5% 50V
2861 © 4822 122 33753 150pF 5% 50V
2863 © 4822 126 14508 180pF 5% 50V
2864 © 4822 126 14508 180pF 5% 50V
2865 © 4822 126 14508 180pF 5% 50V
2866 © 4822 126 14508 180pF 5% 50V
CAPACITORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
2869 © 3198 017 34730 47nF 10% 16V
2870 © 4822 126 13883 220pF 5% 50V
2871 © 4822 126 13883 220pF 5% 50V
2872 © 4822 126 13883 220pF 5% 50V
2873 © 4822 126 13883 220pF 5% 50V
2874 © 4822 126 13883 220pF 5% 50V
2875 © 4822 126 13883 220pF 5% 50V
2876 © 3198 017 44740 470nF 20% 10V
2877 4822 124 40433 47µF 20% 25V
2878 © 2238 586 59812 100nF 10% 50V
2879 © 5322 126 11578 1nF 10% 63V
2880 © 2222 867 15339 33pF 5% 50V
2881 © 4822 126 14249 560pF 10% 50V
2882 © 4822 126 14226 82pF 50V
2883 © 3198 017 44740 470nF 20% 10V
2884 © 3198 017 44740 470nF 20% 10V
2885 4822 124 40196 220µF 20% 16V
2886 © 2238 586 59812 100nF 10% 50V
2887 © 3198 017 34730 47nF 10% 16V
RESISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3801 © 4822 051 30563 56kΩ 5% 0,06W
3802 © 4822 051 30563 56kΩ 5% 0,06W
3803 © 4822 117 12925 47kΩ 1% 0,06W
3804 © 4822 117 12925 47kΩ 1% 0,06W
3805 © 4822 117 12925 47kΩ 1% 0,06W
3806 © 4822 117 12925 47kΩ 1% 0,06W
3807 © 4822 051 30103 10kΩ 5% 0,06W
3808 © 4822 051 30103 10kΩ 5% 0,06W
3809 © 4822 051 30103 10kΩ 5% 0,06W
3810 © 4822 051 30103 10kΩ 5% 0,06W
3811 © 4822 051 30103 10kΩ 5% 0,06W
3812 © 4822 051 30103 10kΩ 5% 0,06W
3813 © 4822 051 30222 2,2kΩ 5% 0,06W
3814 © 4822 051 30222 2,2kΩ 5% 0,06W
3815 © 4822 051 30222 2,2kΩ 5% 0,06W
3816 © 4822 051 30222 2,2kΩ 5% 0,06W
3817 © 4822 051 30479 47Ω 5% 0,06W
3818 © 4822 051 30479 47Ω 5% 0,06W
3819 © 4822 051 30479 47Ω 5% 0,06W
3820 ! 4822 052 10478 4,7Ω 5% NFR25
3821 © 4822 117 12917 1Ω 5% 0,06W
3822 © 4822 051 30103 10kΩ 5% 0,06W
3823 © 4822 051 30102 1kΩ 5% 0,06W
3824 © 4822 051 30474 470kΩ 5% 0,06W
3825 © 5322 117 13029 47kΩ 1% 0,06W
3826 © 4822 117 12891 220kΩ 1% 0,06W
3827 © 5322 117 13056 8,2kΩ 1% 0,06W
3828 © 5322 117 13052 2,7kΩ 1% 0.06W
3829 © 4822 051 30121 120Ω 5% 0,06W
3831 © 4822 051 30471 470Ω 5% 0,06W
3832 © 4822 051 30471 470Ω 5% 0,06W
3833 © 4822 051 30121 120Ω 5% 0,06W
3834 © 4822 051 30472 4,7kΩ 5% 0,06W
3836 © 4822 117 13632 100kΩ 1% 0,06W
3837 © 4822 051 30471 470Ω 5% 0,06W
3839 © 4822 051 30471 470Ω 5% 0,06W
3840 © 4822 051 30223 22kΩ 5% 0,06W
3841 © 4822 051 30153 15kΩ 5% 0,06W
3842 © 4822 051 30102 1kΩ 5% 0,06W
3843 © 4822 051 30102 1kΩ 5% 0,06W
3844 © 4822 051 30101 100Ω 5% 0,06W
3845 © 4822 051 30471 470Ω 5% 0,06W
