Philips MCD170 - Mechanical Parts List (Version;12;98); Mechanical Parts Listing (;12;98)

10 - 2
MECHANICAL PARTSLIST(only for -/12/98)
D1 996510020843 LCD DISPLAY
0003 996510020835 DVD BOARD ASS
0004 996520032155 PCBA-CASS DEC
0080 996510006840 CASS DECK JS-21FB8923-SGS
0081 996510012090 DVD MECHANISM (SONY)
105 996510008651 RUB FOOT DIA10mm T=4mm (GREY)
201 996510020813 FRONT CABINET
202 996510020839 REAR CABINET
203 996510020834 CD TRAY
205 996510018975 LEFT KEY BRACKET
206 996510018976 RIGHT KEY BRACKET
207 996510020819 VOL ROTRAY KNOB
208 996510020823 CD DOOR
209 996510020818 USB DECORATE PLATE
210 996510020829 CASSETTE KEY DOOR
211 996510020816 CASSETTE DOOR
212 996510020836 DUST COVER
213 996500039787 LASER COVER (FOR SANYO CD)
214 996510020833 PRESET - KEY
215 996510020832 PRESET + KEY
216 996510020824 PLAY KEY
217 996510020815 STOP KEY
218 996510020837 REVIEW KEY
219 996510020828 NEXT KEY
220 996510020825 VOL ROTRAY COVER220 996510020825 VOL ROTRAY COVER
221 994000001295 DAMPER GEAR ASS'Y
222 996510020812 STAND BY KEY
223 996510020842 SOURCE KEY
224 996510020791 ROTARY DECORATE RING
225 996510020214 CASS KEY WITH HOLDER
J001 996500042448 CLOSE END WIRE CONNECTOR
J002
!
994000001478 AC PLUG ADAPTOR (-/98)
J003 996510020821 24P FFC.0.5mm L=190mm
J004 996510020838 14P FFC.1mm L=110mm
J005 996510000914 17P FLAT FLEX CABLE 1.25mm
J006
!
994000003633 AC CORD SET VDE APP 6FT (-/98)
J006
!
996510000909 AC CORD VDE APP 2M (-/12)
J007 996510018969 FM ANT L=1.5M
S002 994000004376 SWITCH SL14-22AH-5AN
T001
!
996510020827 TRANSFORMER VDE (-/98)
T001
!
996510029626 TRANSFORMER 230V (-/12)
ACCESSORIES
0005 996510028867 REMOTE CONTROL
0006 994000001192 AM LOOP ANTENNA LAN-031
S001 996510020814 SINGLE SPEAKER BOX (L/R)
J008 996510020831 RCA PLUG CORD 3P L=1.5M
J009 996510002103 CONN. CORD 3.5 ST/PLUGx2 500mm
Note: Only these parts mentioned in the list are
normal service parts.
0003
(only for -/12)
(only for -/98)
