Philips MCD170 - Electrical Parts List; Main Board Electrical Parts; Front Board Electrical Parts

ELECTRICAL PARTSLIST(for all versions)
MAIN BOARD ASSEMBLY
CON3 996510005450 SPK JACK PT-22V11A
F1
!
994000000586 GLASS FUSE W/LEAD 3.15A/250V
IC1 996510000882 IC TFA9842BJ
IC2 996510014303 IC UE2314
JACK1 994000004369 PHONE JACK TC38-063-05-0
JK101 996510012085 S.V/RCA JACK
JK102 996510020826 RCA JACK 6P
Q2 996510010292 SMD TRANSISTORS MMBT3904
Q23 996510005251 MOSFET TRANSISTORS 2SK161-Y
Q5 996510018960 TRANSISTOR ST8050C
SW1 994000002354 CD DOOR SWITCH DLS-02-W-1
U11 996510000881 IC TB2132FNG
U2 996510018852 IC UTC7808
U6 996510003984 IC CYT78L05 (TO-92)
FRONT BOARD ASSEMBLY
D401 996500042438 LED LAMP 2x5x7mm (WHITE)
J025 994000001244 V/PHONE JACK 3.5MM
J802 996510001316 USB SOCKET 4P
P001 996510000998 ROTARY ENCODER
P401 994000004367 OPTIC SENSER FM-6038TM2-5AN
Q101
996510008369
TRANSISTORS MMBT8050D (SOT23)
Q101
996510008369
TRANSISTORS MMBT8050D (SOT23)
Q402 996510009308 TRANSISTORS MMBT8550D
S501 996500042444 TACT SWITCH 6x6mm 4.3mm
U101 996510020841 IC GY669 LQFP44
U102 996510020822 IC AT24C02BN
U103 996510012079 LDO IC UTC1117B33 (-/12/98)
U401 996510020783 IC ET8862Q
Note: Only these parts mentioned in the list are
normal service parts.
11 - 1
U103 99400000283
9
I
C
LM1117S-3.3 (-/58)
