Philips MCD280/21M - Electrical Partslist

12 - 1
ELECTRICAL PARTSLIST
- MISCELLANEOUS -
!
!
!
!
!
!
!
!
!
!
!
!
SW301 9940 000 00636 VOLTAGE SELECTOR SWITCH
R625 9940 000 00678 FUSE RES, 2.2 1/4W ±5%
R626 9940 000 00678 FUSE RES, 2.2 1/4W ±5%
R645 9940 000 00678 FUSE RES, 2.2 1/4W ±5%
JK401 9940 000 00628 JACK FM ANT
JK601 9940 000 00621 SPEAKER JACK WP4-19
JK602 9940 000 00386 HP JACK MSJ-2000
JK603 9940 000 00701 JACK AV4-8.4-13P RED/WHITE
JK604 9940 000 00699 JACK AV1-8.4-13P BLACK
JK701 9940 000 00635 MICRO PHONE JACK
LCD1 9940 000 00645 LCD G892TT-P (B2)
FS301 9940 000 00384 FUSE PTU 1A 250V
FS301 9940 000 00384 FUSE PTU 1A 250V
FS303 9940 000 00638 FUSE PTU2.5A 250V
RL301 9940 000 00687 RELAY ME-7-009 HL
9940 000 00688 FFC CABLE 5P L=40MM
9940 000 00689 FFC CABLE 7P L=90MM
9940 000 00691 FFC CABLE 8P L=50MM
9940 000 00692 FFC CABLE 8P L=80MM
9940 000 00693 FFC CABLE 10P L=120MM
9940 000 00694 FFC CABLE 21P L=125MM
9940 000 00695 FFC CABLE 24P L=90MM
9940 000 00696 RCA CABLE (Y) 1C L=1500MM
9940 000 00697 RCA CABLE (R/W) 2C L=1500MM
9940 000 00698 RCA CABLE (R/B/G) 3C L=1500MM
T301 9940 000 00686 TRANSFORMER EI66 AC120/230V(-/21M)
T302 9940 000 00642 TRANSFORMER EI28(-/21M)
T301 9940 000 00736 TRANSFORMER EI66 (-/30)
T302 9940 000 00737 TRANSFORMER EI28(-/30)
9940 000 00382 POWER AC WIRE VDE 230V(-/21M)
9940 000 00733 AC POWER LINE H03VVH2-F(-/30)
VR701 9940 000 00634 RESISTOR 50K
VC402 9940 000 00378 TRIMMER CAP 220VDC +50%-0%
VC402 9940 000 00378 TRIMMER CAP 220VDC +50%-0%
VC403 9940 000 00378 TRIMMER CAP 220VDC +50%-0%
VC403 9940 000 00378 TRIMMER CAP 220VDC +50%-0%
D309 9940 000 00679 RECTIFIER BRIDGE RS402
D310 9940 000 00679 RECTIFIER BRIDGE RS402
D407 4822 130 81643 BB804-SF0
D408 4822 130 81643 BB804-SF0
U12 9940 000 00721 IC SST39VF800A-70-4C-EK 8M
U301 9940 000 00619 IC,AP1501-50T5 150KHZ
U401 9351 740 80557 IC SM TEA5757H/V1
U402 9940 000 00375 CH-VARIABLE CAP DIODE
U601 9940 000 00624 AMPLIFIER IC TDA7269ASA
U602 9322 150 74668 IC SM TDA7468D
U603 9940 000 00682 IC, NJM4558
U604 9940 000 00682 IC, NJM4558
U701 9940 000 00682 IC, NJM4558
U702 9940 000 00683 KARAOKE ECHO IC BU9253FS
