Philips MCD772 - Page 41

Factory partlist
D007 MCD772 DISPLAY BOARD ASS'Y
Factory Partlist--DVD Parts
R109 CARBON FILM RESISTOR 10K 1/8W J-52
R111 CARBON FILM RESISTOR 10K 1/8W J-52
R113 CARBON FILM RESISTOR 10K 1/8W J-52
R114 CARBON FILM RESISTOR 10K 1/8W J-52
R105 CARBON FILM RESISTOR 33K 1/8W J-52
R106 CARBON FILM RESISTOR 33K 1/8W J-52
R107 CARBON FILM RESISTOR 33K 1/8W J-52
R108 CARBON FILM RESISTOR 33K 1/8W J-52
R112 CARBON FILM RESISTOR 47 1/8W J-52
R110 CARBON FILM RESISTOR 4.7K 1/8W J-52
R104 CARBON FILM RESISTOR 47K 1/8W J-52
R101 CARBON FILM RESISTOR 5.6 1/2W J-52
R102 CARBON FILM RESISTOR 5.6 1/2W J-52
C102 CERAMIC CAP. 104P 50V K-5
C103 CERAMIC CAP. 104P 50V K-5
C104 CERAMIC CAP. 104P 50V K-5
C101 ELECTROLYTIC CAP.47u 16V L-5 5X5
D701 DIODE 4148-52
D703 DIODE 4148-52
D704 DIODE 4148-52
IC101 IC PT6311/SC16311/CD16311
S101 IR SENSOR SMALL BLACK
SW101 TACT SWITCH TS-1307-01 6X6X5
SW103 TACT SWITCH TS-1307-01 6X6X5
SW104 TACT SWITCH TS-1307-01 6X6X5
SW105 TACT SWITCH TS-1307-01 6X6X5
SW106 TACT SWITCH TS-1307-01 6X6X5
SW107 TACT SWITCH TS-1307-01 6X6X5
SW108 TACT SWITCH TS-1307-01 6X6X5
SW109 TACT SWITCH TS-1307-01 6X6X5
SW102 TACT SWITCH HCT-1106W 6X3X4.3
VFD101 VFD DISPLAY NE-770D-1.GB
JP101 BARE WIRE Φ0.6X40mm (375m=1kG)
JP102 BARE WIRE Φ0.6X40mm (375m=1kG)
JP103 BARE WIRE Φ0.6X40mm (375m=1kG)
JP104 BARE WIRE Φ0.6X40mm (375m=1kG)
JP105 BARE WIRE Φ0.6X40mm (375m=1kG)
JP106 BARE WIRE Φ0.6X40mm (375m=1kG)
JP107 BARE WIRE Φ0.6X40mm (375m=1kG)
JP108 BARE WIRE Φ0.6X40mm (375m=1kG)
JP109 BARE WIRE Φ0.6X40mm (375m=1kG)
JP110 BARE WIRE Φ0.6X40mm (375m=1kG)
JP111 BARE WIRE Φ0.6X40mm (375m=1kG)
JP112 BARE WIRE Φ0.6X40mm (375m=1kG)
JP113 BARE WIRE Φ0.6X40mm (375m=1kG)
JP114 BARE WIRE Φ0.6X40mm (375m=1kG)
JP115 BARE WIRE Φ0.6X40mm (375m=1kG)
JP116 BARE WIRE Φ0.6X40mm (375m=1kG)
JP117 BARE WIRE Φ0.6X40mm (375m=1kG)
JP118 BARE WIRE Φ0.6X40mm (375m=1kG)
VFD DISPLAY PCB 35-MCD772-01A1
28 WIRE 200 2.0/12PX1 2.0/9PX1
UNDERLAY VFD BLACK SPONGE 20X20X2 40°
UNDERLAY IR MCD770 IR RECEIVER BRACKET(ABS)
D005 MCD772 USB BOARD ASS'Y
J301 USB JACK A-TYPE 4P FEMALE 90 DIP TYPE
26SHIELDINGING#WIRE160 2.0/4PX1 2.0/4PX1
13-4
