Philips MCD772 - Page 42

USB PCB 35-MCD772-03A1
D015 MCD772/TC540 AUX BOARD ASS'Y
R501 CARBON FILM RESISTOR 560 1/8W J-52
R502 CARBON FILM RESISTOR 560 1/8W J-52
C501 CERAMIC CAP. 332p 50V K-5
C502 CERAMIC CAP. 332p 50V K-5
J501 RCA SOCKET 2P AV2-8.4-14 RED/WHITE
26SHIELDINGING WIRE130#2.0/3PX1 2.0/3PX1
AUX PCB 35-MCD772-05A1
D018 ECO6-05 TUNER BOARD ASS'Y(NO RDS)
CN1 PINS CONNECTOR 2.0X2X4P H8
BLACK SPONGE 5X5X2 40°
SHIELDINGING BOX F-8E 28X26X13 (PLATING)
5760IC TUNER BOARD ASS'Y
R18 CHIP RESISTOR 100K 1/16W J(0603)
R15 CHIP RESISTOR 10K 1/16W J(0603)
R16 CHIP RESISTOR 10K 1/16W J(0603)
R8 CHIP RESISTOR 10K 1/16W J(0603)
R19 CHIP RESISTOR 10 1/16W J(0603)
R2 CHIP RESISTOR 1M 1/16W J(0603)
R3 CHIP RESISTOR 1M 1/16W J(0603)
R12 CHIP RESISTOR 1M 1/16W J(0603)
R4 CHIP RESISTOR 4.7K 1/16W J(0603)
R5 CHIP RESISTOR 4.7K 1/16W J(0603)
R6 CHIP RESISTOR 4.7K 1/16W J(0603)
R1 CHIP RESISTOR 47 1/16W J(0603)
R11 CHIP RESISTOR 10M 1/16W J (0603)
R13 CHIP RESISTOR 820 1/16W J(0603)
R14 CHIP RESISTOR 820 1/16W J(0603)
C14 CHIP CAP.10P 50V J (0603) NPO
R22 CHIP RESISTOR 330 1/16W J(0603)
C20 CHIP CAP.12P 50V J(0603)NPO
C25 CHIP CAP.223P 50V M (0603) Y5V
C21 CHIP CAP.39P 50V J (0603) NPO
C8 CHIP CAP.47P 50V J(0603)NPO
C25 CHIP CAP.224P 50V M (0603) Y5V
C3 CHIP CAP.224P 50V M (0603) Y5V
C4 CHIP CAP.224P 50V M (0603) Y5V
C5 CHIP CAP.224P 50V M (0603) Y5V
C1 TANTALUM CAP. 22u 6.3V (A) (3216)
C18 TANTALUM CAP. 22u 6.3V (A) (3216)
C19 TANTALUM CAP. 22u 6.3V (A) (3216)
C22 TANTALUM CAP. 22u 6.3V (A) (3216)
C24 TANTALUM CAP. 22u 6.3V (A) (3216)
C7 CHIP CAP.27P 50V J(0603) NPO
C6 CHIP CAP.100P 50V K (0603) X7R
C23 CHIP CAP.100P 50V K (0603) X7R
C10 CHIP CAP.103P 50V K (0603) X7R
C11 CHIP CAP.103P 50V K (0603) X7R
C15 CHIP CAP.103P 50V K (0603) X7R
C16 CHIP CAP.103P 50V K (0603) X7R
C17 CHIP CAP.103P 50V K (0603) X7R
C13 CHIP CAP.104P 50V M (0603) Y5V
C12 CHIP CAP.104P 50V M (0603) Y5V
C9 CHIP CAP.104P 50V M (0603) Y5V
L1 CHIP INDUCTOR 120n (0603)
L7 CHIP INDUCTOR 39n J (0603)
L8 CHIP INDUCTOR 10U (0603)
DZ1 CHIP ZENER DIODE 3.6V 1/2W (LL-34)
Q2 CHIP TRANSISTOR 9014 (SOT-23)
13-5
Factory partlist--DVD Parts
