MECHANICAL & ACCESSORIES PARTS LIST
1 996510010723 LENS-CD DOOR /05/12
2 996510010722 DOOR-CD
3 996510010724 HOLDER CD DOOR CARRIER (L)
4 994000004302 COVER POWER BUTTON
5 996510010728 KNOB-VOLUME
6 996510010726 LENS DISPLAY
7 996510010725 HOLDER CD DOOR CARRIER (R)
8 996510010729 LENS BAR
9 996510010721 CABINET FRONT
11 996510010727 BUTTON POWER/SOURCE
15 994000004325 BELT MOTOR
17 996510010720 CABINET REAR FOR /12/05
19-21 996520032987 STAND PORTION OF MCM277
22 9940 000 04323 CD DAMPER (BLACK) 20DEG
23 996510010437 CD MECHANISM M93BGP-BF
24 9940 000 01664 DAMPER GEAR ASSEMBLY
26 9940 000 03384 SPRING TORSION LEFT
28 994000004304 BRACKET OPEN/CLOSE BUTTON
29 994000004324 SPRING CONTROL PANEL
30 996510010730 BUTTON OPEN/CLOSE
31 994000004315 COVER PLAY BUTTON
32 994000004309 BUTTON FW/FF
33 996510010732 PANEL FUNCTION /12/05
34 996510010733 COVER FUNCTION PANEL 05/12/98
35 996510010731 BUTTON FUNCTION
36 994000004308 BUTTON PLAY
37 994000004333 IR LENS
38 994000004316 PULLEY SERVO MOTOR
39 994000004314 BRACKET FUNCTION PANEL
40 996510006485 CD/MCU BOARD ASS'Y (M93) /05/12
SPK 996510010734 SPEAKER BOX /05/12
FMA 994000004329 FM ANT WIRE 75R 1.0M
REM 996510028568 REMOTE CONTROL /05/12
AML 994000004331 AM LOOP ANT 164X75MM
ACW ! 994000002223 POWER AC WIRE BSI /05
ACW ! 994000001675 POWER AC WIRE VDE 230V /12
FFC1 994000004281 FFC 21P P1.25MM L110MM C TYPE
FF1 996510006481 FFC 7P P1.25MM L155MM D TYPE
T901 ! 994000004244 POWER TRASFO AC230V H50 /05/12
T902 ! 994000004245 POWER TRASFO EI-28 AC230V /05/12
RF401 994000004237
Note: Only these parts mentioned in the list are
normal service parts.
9-2
FM FRONT END MODULE /05/12
1 996510012871 LENS-CD DOOR /98
17 996510012870 CABINET REAR /98
ACW ! 994000002082 POWER AC CORD VDE 2C 1.5M /98
T901 ! 994000004431 POWER TRASFO AC115/230V /98
REM 996510028568 REMOTE CONTROL /98
33 996510012873 PANEL FUNCTION /98
