Philips MCM277 - Parts Lists; Electrical Parts Lists for Main, Display;MCU, CD;USB, Audio Processor Boards

ELECTRICAL PARTS LIST
CF401 994000004236 FM CERAMIC FILTER 10M7 IC402 994000004234 VAR. CAP DIODE HN-1V02H
CF402
994000004236 FM CERAMIC FILTER 10M7 IC501 996510006486 IC MN101CF91D MCU TQFP048
D100 996510010718 DIODE BZX79-C4V3 IC504 994000005674 IC BR24L02F-WE2
D128 994000004422 SCHOTTKY, PMEG2010 EA IC601 996500041701 IC TDA7468D SOUND SO28
D165 994000004422 SCHOTTKY, PMEG2010 EA IC610 994000004225 IC LM317P VOL REGULATOR
D300 996510006964 DIODE 1N5819 DO-41 IC701 994000004256 IC HT1622 LCD DRIVER
D302 996510000271 DIODE RLS4148 LL-34 IC801 994000004219 IC TDA1517 POWER AMPLIFIER
D303 994000004285 ZENER DIODE UDZS6.8B UMD2 IC901 996500040080 IC AP1117E33LA REGULATOR
D304 994000004285 ZENER DIODE UDZS6.8B UMD2 JK701 996510010715 USB JACK 4P
D305 994000004285 ZENER DIODE UDZS6.8B UMD2 JK702 994000003605 MICRO PHONE JACK
D401 996510007742 DIODE, HIGH BAS316 JK801 994000003318 HP JACK D3.6MM
D501 996510010716 DIODE,BZX79-C3V9 JK802 994000004248 SPK TERMINAL PST-403B-01
D502 996510010717 DIODE, BZX79-C4V7 TAPING L100A 994000004279 RADIAL IND. 1.2R 2.2UH +/-5%
D618 996510000271 DIODE RLS4148 LL-34 L155A 994000004279 RADIAL IND. 1.2R 2.2UH +/-5%
D750 996510000271 DIODE RLS4148 LL-34
L156A 994000004279 RADIAL IND. 1.2R 2.2UH +/-5%
D801 996510000271 DIODE RLS4148 LL-34 L157A 994000004279 RADIAL IND. 1.2R 2.2UH +/-5%
D802 996510000271 DIODE RLS4148 LL-34 L159A 994000004226 RAD AXIAL IND. 100UH 3.5R
D803 996510000271 DIODE RLS4148 LL-34 L302 994000004289 TOROIDAL COIL 220UH +/-10%
D804 996510000271 DIODE RLS4148 LL-34 L303 994000004226 RAD AXIAL IND. 100UH 3.5R
D807 996510000271 DIODE RLS4148 LL-34 L304A 996510006488 INDUCTOR 10UH+/-10% 0.1R
D880 996510000271 DIODE RLS4148 LL-34 L403 996510010713 AM ANT 7MM 7M1A2204N
D881 994000004422 SCHOTTKY, PMEG2010 EA L605 994000004227 28UH CORE: 6T 715R 1.2A
D905 996510000271 DIODE RLS4148 LL-34 L620 994000004226 RAD AXIAL IND. 100UH 3.5R
D991 996510000271 DIODE RLS4148 LL-34 L702 994000004279 RADIAL IND. 1.2R 2.2UH +/-5%
D992 996510000271 DIODE RLS4148 LL-34 L810 994000004247 RADIAL AXIAL IND. 8.0UH 60MR
DZ401 996510010712 CH-DIODE, BZX284-C11 L811 994000004247 RADIAL AXIAL IND. 8.0UH 60MR
DZ801 996510007763 ZENER DIODE BZX55C15V L812 994000004247 RADIAL AXIAL IND. 8.0UH 60MR
DZ802 996500041721 ZENER DIODE BZX79-C10 L813 994000004247 RADIAL AXIAL IND. 8.0UH 60MR
DZ803 996510010711 ZENER DIODE BZX79-C5V6 L901 994000002657 AC LINE FILTER 3MH 1A
F601 ! 994000004229 FUSE PTU 2A 250V
LCD701 996510006483 LCD DISPLAY 1/8 DUTY 1/4 STN
F602 ! 994000004228 FUSE S506 T1.6AL 250V LED701 996510006484
LED 4MM WHITE
F901 ! 994000004243 FUSE PTU 1A 250V 3.9X10.5MM
LED702 996510000292 LED 3MM 3R4HD-7(RED)
FF1 996510006481 FFC 7P P1.25MM L155MM M100 994000004253 DC MOTOR JQ32-55K415 DC3V
FMANT 994000004249 RCA JACK RCA-125 Q100 994000004275 TRANSISTOR 2SB709A
IC100 996500041888 IC MN6627954MA DSP Q101 996510006954 CH-TRANSISTOR,BC817-25
IC102 994000004278 IC SCA105 MOTOR DRIVER Q102 996510006954 CH-TRANSISTOR,BC817-25
IC103 996500041890 IC MN101E01J TA MASKING Q103 994000004223 TRANSISTOR 3CA8550
IC104 994000005674 IC BR24L02F-WE2 Q104 996510006954 CH-TRANSISTOR,BC817-25
IC300 994000004287 IC OTI-6888G USB DECODER Q105 996510006954 CH-TRANSISTOR,BC817-25
IC301 994000004286 IC AP34063A CONVERTER Q106 994000004224 TRANSISTOR 3DA8050
IC302 996510010719 IC AT27C512R OTP EPROM Q107 994000004223 TRANSISTOR 3CA8550
IC302 994000004288 IC W27C512-45Z EPROM Q301 996510000939 TRANSISTOR BC807-25 PNP
IC401 994000004235 IC TEA5762H/V1 Q302 996510006954 CH-TRANSISTOR,BC817-25
9-3
