Philips MCM277 - Parts Lists; Electrical Parts Lists for Key, AC Power, SP;ANT, RC, Tuner Boards

ELECTRICAL PARTS LIST
Q303 996510000939 TRANSISTOR BC807-25 PNP X300 994000004284 XTAL 14.318MHZ +/-20PPM 20PF
Q501 996510006954 CH-TRANSISTOR,BC817-25 X401 994000004231 X'TAL 75KHZ +/-20PPM DT381
Q502 994000004267
TRANSISTOR MPS8050S
X501 994000005671 XTAL 32.768KHZ +/-20PPM 12PF
Q503 996510006954 CH-TRANSISTOR,BC817-25 X502 994000004266 X'TAL 4.194304MHZ 30PF
Q504 996510006954 CH-TRANSISTOR,BC817-25 XR11 994000004238 X'TAL 4.332MHZ +/-20PPM
Q601 994000004224 TRANSISTOR 3DA8050 HFE=120-200
Q610 994000004223 TRANSISTOR 3CA8550 HFE=120-220
Q631 994000004223 TRANSISTOR 3CA8550 HFE=120-220
Q701 994000004224 TRANSISTOR 3DA8050 HFE=120-200
Q702 994000004224 TRANSISTOR 3DA8050 HFE=120-200
Q803 994000004218 N-CHANNEL MOS TRANS PHP20N06T
Q905 994000004224 TRANSISTOR 3DA8050 HFE=120-200
RF401 994000004237
FM FRONT END MODULE FE450-G11
RI501 996510001366 IR SENSOR (OPTO)
RL901 ! 994000004246 RELAY ME-7-006-HSL DC6V AC10A
SW501 994000004283 DETECT SWITCH DTS-18 1P1T
SW502 994000004283 DETECT SWITCH DTS-18 1P1T
SW506 994000004259 SWITCH TACT TSA-06430-150
SW701 994000004259 SWITCH TACT TSA-06430-150
SW702 994000004259 SWITCH TACT TSA-06430-150
SW703 994000004259 SWITCH TACT TSA-06430-150
SW704 994000004259 SWITCH TACT TSA-06430-150
SW705
994000004259 SWITCH TACT TSA-06430-150
SW708 994000004259 SWITCH TACT TSA-06430-150
SW709 994000004259 SWITCH TACT TSA-06430-150
SW710 994000004259 SWITCH TACT TSA-06430-150 Note: Only these parts mentioned in the list are
SW715 994000004259 SWITCH TACT TSA-06430-150 normal service parts.
SW716 994000004259 SWITCH TACT TSA-06430-150
SW717 994000004259 SWITCH TACT TSA-06430-150
T401 994000004518 AM IFT YELLOW 7MM C712KC-004
T402 994000004518 AM IFT YELLOW 7MM C712KC-004
T403 996510010714 AM IFT BLACK 7MM 7M4A2011N
T404 994000004519 FM IFT BLACK 7MM KS2599
T405 994000004517 AM OSC BROWN 7MM 7M1A2146
T901 ! 994000004244 POWER TRASFO AC230V H50.
T902 ! 994000004245 POWER TRASFO EI-28 AC230V
UR11 994000004239 IC SAA6588T RADIO RECEIVERS
UR12 996510001350 IC LM78L05 3-TERMINAL TO-92
VC403 994000001615 TRIMMER CAP 10PF N450
VR401 994000004232 VARI RES 100K 3P 1/10W+/-30%
VR701 994000004258 ROTARY ENCODER
X100 994000004273 CER RESONATOR 16.93MHZ +/-0.5%
X101 996510000295 XTAL 8.38MHZ +/-20PPM CAP=20PF
9-4
