Philips MCM390 - Electrical Parts List (Part 2); Display, Cassette, and Rectifier Board Components

13 - 2
ELECTRICAL PARTSLIST
DISPLAY AND MCU BOARD
SW701 9940 000 01444 TACT SWITCH
SW702 9940 000 01445 TACT SWITCH
SW703 9940 000 01445 TACT SWITCH
SW704 9940 000 01445 TACT SWITCH
SW705 9940 000 01445 TACT SWITCH
SW706 9940 000 01445 TACT SWITCH
SW707 9940 000 01445 TACT SWITCH
SW708 9940 000 01445 TACT SWITCH
SW709 9940 000 01445 TACT SWITCH
SW710 9940 000 01445 TACT SWITCH
SW711 9940 000 01445 TACT SWITCH
SW712 9940 000 01445 TACT SWITCH
SW713 9940 000 01445 TACT SWITCH
SW714 9940 000 01445 TACT SWITCH
9940 000 01446 FFC CABLE 16P P1.25 L200
EN701 9940 000 01437 ROTARY ENCODER
IC701 9940 000 01438 TMP86CS25FG-6BR2 M390
IC702 9940 000 01439 M24C01WMN6T EEPROM
IC703 4822 209 31981 SAA6579T
LCD701 9940 000 01441 LCD DISPLAY 81057TT-H
LED701 9940 000 01442 LED 5.25X2.9 RED
LED702 9940 000 01443 LED 5.2X3.4 BLUE OVAL
RS701 9322 155 82667 IR RECEIVER TSOP2236
CASSETTE BOARD
7720 9322 167 09668 IC SM AN17150ATA
5703 9940 000 01432 OSC COIL-RED
7610 5322 209 11306 HEF4094BT
7786 9940 000 01433 TRANSISTOR (FET) J112
RECTIFIER BOARD AND MISCELLANEOUS
D107 9965 000 19419 RETCTIFIER DIODE 1N5401
D108 9965 000 19419 RETCTIFIER DIODE 1N5401
D109 9965 000 19419 RETCTIFIER DIODE 1N5401
D110 9965 000 19419 RETCTIFIER DIODE 1N5401
RL101 9940 000 01448 9V DC RELAY 10A
F101 9940 000 01447 FUSE 2.5A 250V D5X20MM
F102 4822 071 53152 FUSE 3.15A
F103 4822 071 53152 FUSE 3.15A
9940 000 01452 DC COOLING FAN
9940 000 01451 VDE POWER CORD
9940 000 01465 STANDBY TRANSF. /21
9940 000 01455 STANDBY TRANSF. /22
9940 000 01466 POWER TRANSF. 230V
9940 000 01449 POWER TRANSF. 120/230V
!
!
!
!
!
!
!
!
!
