Technical Reference
MCP9350i 4. EN 7
4.2.2. System Cable Definition Table
Cable
Number
Cable Name Start End(s)
1 FP_AUDIO_CABLE MB J8H1 FP BOARD JAUDIO1
2 FP_1394_CABLE MB J5A2 FP BOARD JFP1
3 FP_USB_CABLE MB J8A2 FP BOARD JFP2
4 VFD_USB_CABLE MB J6A1 VFD Board JUSB1
5 IR_BLASTER_INTERNAL_CABLE MB J9C2 VFD BOARD J2
6 SW_RF_CABLE VFD Board JRF1 SW BOARD JRF2
7 V-TYPE_CABLE MB J7A2 (1) SW BOARD JFP1
(2) CARD READER
8 SATA_HDD_CABLE MB J7F1 HDD
9 ATA33_ODD_CABLE MB EIDE ODD
10 MD_CABLE MB MD CARD MD RJ-11 CONNECTOR BOARD
11 ADD2_SCART_CABLE MB J9H1 (1) ADD2 SCART DAUGHTER CARD
(2) GRAPHICS CARD (ADD2 BOARD)
12 A/V_1x10_CABLE TV tuner AV2 TV daughter card
