EN 6 4. MCP9350i
Technical Reference
4.2. System Cable Definition
4.2.1. System Cable Schematic
J8H1
FP_AUDIO
J5A2 J8A2
JAUDIO1
FP_1394
FP_USB
Cable 1
Cable 2
Cable 3
FP I/O Board
PCI Riser TV Tuner Card
PCI Bus PCI Bus
TV Daughter Card
JFP1 JJFP2
VFD Board
JUSB1 J2
J9H1 J6A1 J9C2 J7A2 SATA EIDE
-
A
V2
PCI-E Riser Graphics Card
PCI-E Bus PCI-E Bus
Cable 12
SCART Daughter Card
-
-
Cable 11
SW Board
Card Reader
JRF1
Cable 4
Cable 5
JFP1
-
JRF2
Cable 6
MD RJ-11 Board
RF Board
Cable 7
MD Card
MDC
- -
HDD
SATA
ODD
EIDE
Cable 8
Cable 9
Cable 10
MOTHERBOARD
Front panel
Front panel
Front panel
Rear panel
Rear panel
Rear panel Rear panel
Rear panel
Figure 4.2-1
