Diagnostic Software
EN 42 DVDR615, MRV6405.
Analogue Board (ANAB)
Execution Time Until user confirmation.
User Input None
Error Number Description
100500 Remote Control test succeeded
100501 DCB Remote control; test failed
100502 DCB Remote control; test aborted
100503 The DCB could not be accessed by the analogue board.
100504 DCB Remote control; no user input received
Example DS:> 1005
100500:
Test OK @
Nucleus Name DS_DCB_Led
Nucleus Number 1006
Description Switch the record LED on, and after confirmation off.
The user confirms by pressing the REC key, STOP key, or the PLAY key on the local
keyboard. The PLAY key confirms that the LED is on and the REC key
Technical - Issue the command to light the record LED via the analogue board and wait for
confirmation by the user
Execution Time Until user confirmation.
User Input None
Error Number Description
100600 Switching Led on succeeded
100601 The DCB could not be accessed by the analogue board.
100602 There was no response from the analogue board.
100603 The DCB did not light the record LED.
100604 The user skipped the rest of the DCB_Led test.
100605 The user returned an unknown confirmation:
100606 The returned errorcode from the analogue board is un-
known
Example DS:> 1006
100600:
Test OK @
Nucleus Name DS_ANAB_CommunicationEcho
Nucleus Number 1100
Description Check the communication between the digital board and the analogue board by issu-
ing some echo string.
Technical Send command P_DS_ANACOM_ECHO with the parameter string “Hello Analogue
board” to the analogue board and read back the result
Execution Time Less than 1 second
User Input None
Error Number Description
Communicating with the analogue board succeeded
The test returned the wrong string
Communicating with the analogue board failed
The analogue board returned an unexpected result
110000
110001
110002
110103
Example DS:> 1100
110000: Hello Analogue Board
Test OK @
Nucleus Name DS_ANAB_CommunicationIicNvram
Nucleus Number 1101
Description Check the communication between the digital board and the NVRAM on the analogue
board.
Technical Send command P_DS_ANACOM_NVRAM with no parameters to the analogue board
and read back the result
Execution Time Less than 3 seconds
User Input None
Error Number Description
110100 Communicating with the NVRAM on the analogue board
succeeded
