Diagnostic Software
EN 44 DVDR615, MRV6405.
Example DS:> 1104
110400:
Test OK @
Nucleus Name DS_ANAB_CommunicationIicAVSelector
Nucleus Number 1105
Description Check the communication between the digital board and the A/V-selector on the ana-
logue board
Technical Send command P_DS_ANACOM_AV_SELECTOR with no parameters to the ana-
logue board and read back the result
Execution Time Less than 1 second
User Input None
Error Number Description
110500 Communicating with the A/V selector on the analogue
board succeeded
110501 The analogue board could not communicate with the A/V
selector
110502 There was an error communicating with the analogue
board
110503 The analogue board returned an unexpected result
Example DS:> 1105
110500:
Test OK @
Nucleus Name DS_ANAB_HardwareVersionGet
Nucleus Number 1106
Description Get the hardware version of the analogue board
Technical Send command P_DS_ANACOM_HARDWARE_VERSION with no parameters to the
analogue board and read back the result
Execution Time Less than 1 second
User Input None
Error Number Description
110600 Reading the hardware version succeeded
110601 The segment containing the hardware version could not be
found
110602 There was an error communicating with the analogue
board
110603 The analogue board returned an unexpected result
Example DS:> 1106
110600: Analogue hardware version : 11
Test OK @
Nucleus Name DS_ANAB_SoftwareVersionBootGet
Nucleus Number 1107
Description Get the software version of the boot software of the analogue board
Technical Send command P_DS_ANACOM_SOFTWARE_VERSION with no parameters to the
analogue board and read back the result
Execution Time Less than 1 second
User Input None
Error Number Description
110700 Reading the boot-software version succeeded
110701 The segment containing the boot-software version could
not be found
110702 There was an error communicating with the analogue
board
110703 The analogue board returned an unexpected result
Example DS:> 1107
110700: Bootcode application version : 11.00.11
Test OK @
Nucleus Name DS_ANAB_SoftwareVersionDownloadGet
Nucleus Number 1108
Description Get the software version of the download software of the analogue board
Technical Send command P_DS_ANACOM_SW_VERSION_DOWN with no parameters to the
analogue board and read back the result
