Diagnostic Software
EN 45DVDR615, MRV640 5.
Execution Time Less than 1 second
User Input None
Error Number Description
110800 Reading the download-software version succeeded
110801 The segment containing the download-software version
could not be found
110802 There was an error communicating with the analogue
board
110803 The analogue board returned an unexpected result
Example DS:> 1108
110800: Download application version : 11.00.06
Test OK @
Nucleus Name DS_ANAB_SoftwareVersionApplGet
Nucleus Number 1109
Description Get the software version of the application software of the analogue board
Technical Send command P_DS_ANACOM_SW_VERSION_APPL with no parameters to the
analogue board and read back the result
Execution Time Less than 1 second
User Input None
Error Number Description
Reading the application-software version succeeded
110900
110901 The segment containing the application-software version
could not be found
110902 There was an error communicating with the analogue
board
110903 The analogue board returned an unexpected result
Example DS:> 1109
110900: Recorder application version : 11.00.23
Test OK @
Nucleus Name DS_ANAB_SoftwareVersionDiagnosticsGet
Nucleus Number 1110
Description Get the software version of the diagnostic software of the analogue board
Technical Send command P_DS_ANACOM_SW_VERSION_DIAG with no parameters to the
analogue board and read back the result
Execution Time Less than 1 second
User Input None
Error Number Description
111000 Reading the diagnostics-software version succeeded
111001 The segment containing the diagnostics-software version
could not be found
111002 There was an error communicating with the analogue
board
111003 The analogue board returned an unexpected result
Example DS:> 1110
111000: Diagnostics application version : 11.00.13
Test OK @
Nucleus Name DS_ANAB_ChecksumProgram
Nucleus Number 1111
Description Check the checksum of the several partitions by recalculating and comparing partition
checksums
Technical Send command P_DS_ANACOM_FLASH_CHECKSUM with no parameters to the
analogue board and read back the result
Execution Time Less than 5 seconds
User Input None
Error Number Description
111100 Checksum calculation succeeded
111101 The FLASH was not accessible
111102 The checksum stored in FLASH is not correct
111103 There was an error communicating with the analogue
board
111104 The analogue board returned an unexpected result
