Diagnostic Software
EN 47DVDR615, MRV640 5.
Audio routing paths (Europe)
4 Input signal is from REAR S-VIDEO(Y/C) IN and will be routed to the digital board.
5 No Routing.
6 No routing.
7 No routing.
8 Input signal is VIDEO(CVBS) from TUNER and will be routed to Y Pin of Rear Y/C Connec-
tor.This will give only black/White Picture .
9 Input signal is from YUV IN and will be routed to YUV OUT.This is possible only if Digital
Board routes back YUV signal received back to the Analogue board(DENC)
10 No routing.
11 No routing.
12 No Routing.
13 No Routing.
14 No Routing.
15 Input CVBS Signal from Tuner is routed to Digital Board..
16 No Routing.
17 No Routing.
18 Input Signal from CVBS Rear In is routed to Digital Board. This is the same as path ID 02.
19 Input Y/C signal from Digital Board is routed to Y/C Rear Out Connector and Input signal from
Y/C Front In Connector is routed to Y/C Digital Board.
20 Y/C signal from Digital Board is routed to Y/C Rear Out Connector and Input signal from Y/
C Rear In Connector is routed to Y/C Digital Board.
23 The Video signal received from the Digital board will be output on Modulator channel 3.
24 The Video signal received from the Digital board will be output on Modulator channel 4.
Nucleus Name DS_ANAB_AudioRouting
Nucleus Number 1113
Description Perform the routing of the audio paths on the analogue board
Technical Send command P_DS_ANACOM_ROUTE_AUDIO with parameters to the analogue
board and read back the result
Execution Time Less than 1 second
User Input The user has to input the correct parameter for the routing (see table 'audio routing'
below)
Error Number Description
111300 Routing the audio on the analogue board succeeded
111301 Routing the audio on the analogue board failed
111302 The user provided wrong input
111303 There was an error communicating with the analogue
board
111304 The analogue board returned an unexpected result
Example DS:> 1113 00
111300:
Test OK @
Path ID Description
0 Input signal is from FRONT AUDIO IN and will be routed to the digital board.
1 Input signal is from FRONT AUDIO IN and will be routed to the digital board.
2 No Routing.
3 Input signal is AUDIO from SCART1 and will be routed to the digital board.
4 Input signal is AUDIO from SCART2 and will be routed to the digital board.
5 No routing.
6 No routing.
7 Input Audio signal is from the digital Board and it will be routed to the SCART1 and SCART2
8 Input AUDIO signal from TUNER and will be routed to SCART2.
9 Input signal is AUDIO from SCART1 and will be routed to SCART2.
10 Input audio signal from SCART2 is routed to SCART1.
11 Input Audio signal is routed from DVIO to SCART2.
12
13 No Routing.
14 Input is Audio Signal from DVIO and it will be routed to Digital Board.
15 Input is Audio Signal from TUNER and it will be routed to Digital Board..
16 No routing.
17 No Routing.
