Diagnostic Software
EN 48 DVDR615, MRV6405.
Audio routing paths (NAFTA)
18 Input signal is from FRONT AUDIO IN and will be routed to SCART2.
21 Input signal is from FRONT AUDIO IN and will be routed to the digital board.
Path ID Description
0 No Routing.
1 Input signal is from FRONT AUDIO IN and will be routed to the digital board.
2 Input signal is from REAR AUDIO IN 2 and will be routed to the digital board.
3 Input Audio Signal is routed from FRONT Cinch In to Digital Board.(This is same as path ID
01)
4 Input Signal is from Rear Cinch In1 and it will be routed to Digital Board..
5 No routing.
6 No routing.
7 No routing.
8 No Routing.
9 No routing.
10 No Routing.
11 No Routing.
12 No Routing.
13 Input Signal is from Digital Board and it will be routed to the digital board.
14 No routing.
15 Input is Audio Signal from TUNER and it will be routed to Digital Board.
16 Input signal is AUDIO from dvio board and will be routed to Digital Board.
17 No routing.
18 No routing.
19 No routing.
20 Input signal is from REAR AUDIO IN 2 and will be routed to the digital board.
21 Input signal is from REAR AUDIO IN 1 and will be routed to the digital board.
22 Input signal is from REAR AUDIO IN 1 and will be routed to the digital board.
23 The Audio signal received from the Digital board will be outputted on Modulator channel 3.
24 The Audio signal received from the Digital board will be outputted on Modulator channel 4.
Nucleus Name DS_ANAB_SelectTunerChannel
Nucleus Number 1114
Description Set the tuner to receive a valid audio and video signal
Technical Send command P_DS_ANACOM_TUNER_FREQ_SELECT with parameters to the
analogue board and read back the result
Execution Time Less than 1 second
User Input <Frequency*16> <video standard id>
Tuner frequency: to tune the tuner to e.g. 216 MHz, this parameter must be 3456.
(Since 216*16 = 3456. This is to avoid the decimal points to the parameter list.)
Video standard id: The table below shows which video standards are possible
Video standard id Europe NAFTA
16
32
48
64
80
96
112
PAL_BG NTSC
PAL_I Invalid
PAL_DK Invalid
SEC_L Invalid
SEC_LS Invalid
SEC_BG Invalid
SEC_DK Invalid
Error Number Description
111400 Setting the tuner channel succeeded
111401 Setting the tuner channel failed
111402 The user provided wrong input
111403 There was an error communicating with the analogue
board
111404 The analogue board returned an unexpected result
Example DS:> 1114 3456 16
111400:
Test OK @
Nucleus Name DS_ANAB_IICWriteRead
Nucleus Number 1115
