Diagnostic Software
EN 49DVDR615, MRV640 5.
Description Perform an IIC write and read action on the analogue board
Technical Send command P_DS_ANACOM_I2C_WRR with parameters to the analogue board
and read back the result
Execution Time Less than 1 second
User Input Writing:
[<W>|<w>] [I2C address] [number of data bytes to write]
with
<data[0]...data[n]> Max 16 data bytes (n < 16).
Reading:
[<R>|<r>] [I2C address] [number of data bytes to read]
Max 16 data bytes (n < 16).
Error Number Description
111500 Reading and writing IIC on the analogue board succeeded
111501 The user provided wrong input
111502 Reading and writing IIC on the analogue board failed
111503 There was an error communicating with the analogue
board
111504 The analogue board returned an unexpected result
Example DS:> 1115 w 0x94 2 0x06 0x02
111500:
Test OK @
Nucleus Name DS_ANAB_ClockAdjust
Nucleus Number 1116
Description Set the clock to the value passed through in the YYYY MM DD HH MM SS format
Technical Send command P_DS_ANACOM_CLOCK_ADJUST with parameters to the analogue
board and read back the result
Execution Time Less than 1 second
User Input <YYYY> <MM> <DD> <HH> <MM> <SS>
Error Number Description
111600 Adjusting the clock succeeded
111601 Adjusting the clock failed
111602 The user provided wrong input
111603 There was an error communicating with the analogue
board
111604 The analogue board returned an unexpected result
Example DS:> 1116 2002 11 11 11 11 11
111600:
Test OK @
Nucleus Name DS_ANAB_ClockReference
Nucleus Number 1117
Description Generate a 1 kHz signal on pin 7 (INT) of the clock IC
Technical Send command P_DS_ANACOM_CLOCK_REFERENCE with no parameters to the
analogue board and read back the result
Execution Time Less than 1 second
User Input None
Error Number Description
111700 Generating the signal on the designated pin succeeded
111701 Generating the signal on the designated pin failed
111702 There was an error communicating with the analogue
board
111703 The analogue board returned an unexpected result
Example DS:> 1117
111700:
Test OK @
Nucleus Name DS_ANAB_ClockCorrection
Nucleus Number 1118
Description Store the clock IC correction value in NVRAM
Technical Send command P_DS_ANACOM_CLOCK_CORRECTION with parameters to the an-
alogue board and read back the result
Execution Time Less than 1 second
User Input The correction value for the clock
Error Number Description
