Diagnostic Software
EN 61DVDR615, MRV640 5.
Example Is the PCI connector available [Default = 'N']
>N
Enter the size of the available RAM memory (Mbyte) [Default = 32]
>32
Enter the size of the available NOR Flash in Bank 0 (Mbyte),type 0 if not available
[Default = 8]
>8
Enter the size of the available NOR Flash in Bank 1 (Mbyte),type 0 if not available
[Default = 0]
>0
Enter the size of the available NAND Flash (Mbyte),type 0 if not available [Default = 0]
>0
Board name: my board
Hardware ID: 0
Codec IC: PNX7100_MF2
Video Input Processor IC: SAA7118
Progressive Scan Deinterlacer IC: None
Progressive Scan Denc IC: ADV7196
I-Link physical layer circuit IC: PDI1394P25
I-Link link layer circuit IC: PDI1394P40
Audio clock: Clock scheme 1
Bit engine connector: available
IDE connector 1: available
IDE connector 2: not available
PCI connector: not available
RAM size 32MByte
ROM size (NOR FLASH bank 1) 8MByte
ROM size (NOR FLASH bank 2) Not available
ROM size (NAND FLASH) Not available
Settings ID: 6D7920626F61726400020300010101020101000020080000
Program the settings? [Y/N]
Programming the settings values. Please wait...
122700:
Test OK @
Nucleus Name DS_SYS_SettingsDisplay
Nucleus Number 1228
Description Show the settings that are programmed in the BROM on the digital board.
Technical - Set-up IIC-bus.
- Read Digital Board Settings from boot EEPROM.
- Display the settings.
Execution Time 1 second
User Input None.
Error Number Description
122800 The settings were successfully displayed.
122801 IIC access failed.
122802 Invalid settings
Example DS:> 1228
Settings ID: 6D7920626F61726400020300010101020101000020080000
Board name: my board
Hardware ID: 0
Codec IC: PNX7100_MF2
Video Input Processor IC: SAA7118
Progressive Scan Deinterlacer IC: None
Progressive Scan Denc IC: ADV7196
I-Link physical layer circuit IC: PDI1394P25
I-Link link layer circuit IC: PDI1394P40
Audio clock: Clock scheme 1
Bit engine connector: available
IDE connector 1: available
IDE connector 2: not available
PCI connector: not available
RAM size 32MByte
ROM size (NOR FLASH bank 1) 8MByte
ROM size (NOR FLASH bank 2) Not available
ROM size (NAND FLASH) Not available
Bit Engine: AV 2.0
122800:
Test OK @
