Diagnostic Software
EN 60 DVDR615, MRV6405.
Technical - Evaluate user input.
- Set-up IIC-bus.
- Write data to boot EEPROM.
- Update checksum.
Execution Time 1 second
User Input A large hexadecimal value that represents the digital board settings obtained from
the DbString.exe program or from a reference set.
Error Number Description
122600 The settings were successfully programmed.
122601 User input is invalid.
122602 IIC access failed.
Example DS:> 1226 646961677473746201010200010101010101000020080000
122600:
Test OK @
Nucleus Name DS_SYS_SettingsSetup
Nucleus Number 1227
Description Investigates the system by means of partial auto-detection. After that it programs the
settings into the boot EEPROM on the digital board.
User Input The nucleus asks the user some questions, and the user can response them with de-
fined answers.
Example DS:> 1227
Investigating the system, please wait...
Enter a name for the digital board:
>my board
Enter the HW ID of the digital board [Default = 0]
>0
Wich type of Codec IC is present [Default = 2]
0. None
1. PNX7100_MF1
2. PNX7100_MF2
3. PNX7100_MF3
>2
Wich type of VIP IC is present [Default = 3]
0. None
1. SAA7114
2. SAA7115
3. SAA7118
4. SAA7119
>3
Wich progressive scan DeInterlacer is present [Default = 0]
0. None
1. FLI1200
2. FLI2200
3. S2301
>0
Wich progressive scan denc is present [Default = 1]
0. None
1. ADV7196
>1
Wich 1394 physicallayer IC is present [Default = 1]
0. None
1. PDI1394P2540
>1
Wich 1394 linklayer IC is present [Default = 1]
0. None
1. PDI1394L40
>1
Wich audio clock scheme is used [Default = 2]
0. None
1. Audio clock scheme 0
2. Audio clock scheme 1
3. Audio clock scheme 2
>2
Is the Basic engine (AV1.x/2.x) connector available [Default = 'Y']
>Y
Is IDE connector 1 available [Default = 'Y']
>Y
Is IDE connector 2 available [Default = 'N']
>N
