1-15-3 E9015TI
2) LP/SLP Mode
Fig. 2
"H"
"Z"
"H"
"L" "L"
18 RF-SW
F-AD
(Internal Signal)
C
-DRIVE
PB CTL
78 C-F/R
16 H-A-SW
15 ROTA
STILL STILL
AT
ST
BL
Stop detection (T2)
Acceleration Detection (T1)
Slow Tracking Value
Reversal Limit Valu
e
FRAME ADVANCE
The first rise of RF-SW after a rise in F-AD signal
20ms
