CABINET DISASSEMBLY INSTRUCTIONS
1. Disassembly Flowchart
This flowchart indicates the disassembly steps to gain
access to item(s) to be serviced. When reassembling,
follow the steps in reverse order. Bend, route, and
dress the cables as they were originally.
2. Disassembly Method
ID/
LOC.
No.
PART
REMOVAL
Fig.
No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
Note
[1] Top Cover D1 7(S-1) -
[2] Front Unit D2
(S-2), *7(L-1), *CN505,
*CN2014
1
1-1
1-2
1-3
[3] Top Bracket D2 2(S-3), 2(S-4) -
[4] Front CBA D3
3(S-5),
Volume Knob
-
[5]
DVD Mecha
Unit
D4
3(S-6), 2(S-7), *CN401,
*CN601, *CN901,
*CN902
2
[1] Top Cover
[7] DVD Mecha
Assembly
[2] Front Unit
[3] Top Bracket
[10] Rear Pane
[6] DVD Main
CBA Unit
[5] DVD Mecha
Unit
[8] PS CBA
Holder
[13] Tuner CBA
[20] Jack-B CBA
[22] Main CBA
[9] Power Supply
CBA (For VCR/DVD)
[12] Fan Cover
[17] Deck
Assembly
[11] Fan
[18] DVD OPEN
/CLOSE CBA
[15] LED CBA
[23] AF Module, Power Transformer
and AM/FM Tuner Unit
[14] VCR
Chassis Unit
[19] DAC CBA
[16] Jack-C CBA
[24] Deck
Pedestal
[4] Front CBA
[25] Side
Bracket
[21] Jack-A CBA
[6]
DVD Main
CBA Unit
D5 *CN201, *CN301
3
3-1
3-2
4
[7]
DVD Mecha
Assembly
D5 ---------- -
[8]
PS CBA
Holder
D6
3(S-8), Earth Plate,
*CN050, *CN1008
-
[9]
Power Sup-
ply CBA (For
VCR/DVD)
D6 4(S-9) -
[10] Rear Panel D7
11(S-10), 4(S-11),
(S-12), *2(L-2)
-
[11] Fan D7
4(S-13), 4(S-14),
Connector
-
[12] Fan Cover D7 ---------- -
[13] Tuner CBA D8 *CN702, *CN1202 -
[14]
VCR Chassis
Unit
D8
5(S-15), 2(S-16),
(S-17), *CN503,
*CN2020
-
[15] LED CBA D8 2(S-18) -
[16] Jack-C CBA D8 (S-19) -
[17]
Deck Assem-
bly
D9
Desolder, 3(S-20),
Cylinder Shield
(S-21), (S-22)
4,5
[18]
DVD OPEN/
CLOSE CBA
D10 Desolder -
[19] DAC CBA D10 *CN7105, *CN7104 -
[20] Jack-B CBA D10 *CN2017 -
[21] Jack-A CBA D10 *CN2018 -
[22] Main CBA D10 ---------- -
[23]
AF Module,
Power Trans-
former and
AM/FM Tuner
Unit
D11
4(S-22), 2(S-23),
4(S-24),
Trans Holders
-
[24]
Deck
Pedestal
D12
7(S-25),
Pedestal Shield
-
[25] Side Bracket D12 (S-26) -
↓
(1)
↓
(2)
↓
(3)
↓
(4)
↓
(5)
ID/
LOC.
No.
PART
REMOVAL
Fig.
No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
Note
