Philips MX5100VR - Signal Name Abbreviations

1-6-1 E9515SNA
SIGNAL NAME ABBREVIATIONS
Signal Name Function
-FL
FIP Drive Power Supply
2CH 2 Channel Audio Signal
33/36M DA Converter Clock
6CH Dolby Digital 5.1ch Audio Signal
8POUT-1/2
Control SCART 1 8Pin Level by
using 8POUT-1 and 8POUT-2
A-COM Audio Head Common
A-IN Audio Signal Input
A-MODE Hi-Fi Tape Detection Signal
A-MUTE-H
Audio Mute Control Signal
(Mute = “H”)
A-OUT Audio Signal Output
A-PB/REC
Normal Audio Play Back/Record
Signal
AC IN
AC Power Supply Input
ADAC
Advanced Digital audio Acoustic
Coding
AE-H Audio Erase Head
AFC
Automatic Frequency Control
Signal
AGC IF AGC Control Signal
AL+12V
Always +12V with AC Plug
Connected
AL+2.35V
Always +2.35V with AC Plug
Connected
AL+20.5V/
+12V
Always +15V/+12V with AC Plug
Connected
AL+4V
Always +4V with AC Plug
Connected
AL+5V
Always +5V with AC Plug
Connected
AL+9V
Always +9V with AC Plug
Connected
AL-30V
Always -30V with AC Plug
Connected
AMPC CTL AMP Connected Terminal
AMPVcc AMPVcc
AMPVREF in V-Ref for CTL AMP
AMPVREF
OUT
V-Ref for CTL AMP
ASPECT Aspect Switching Signal
AVcc
A/D Converter Power Input/
Standard Voltage Input
C-CONT Capstan Motor Control Signal
C-F/R
Capstan Motor FWD/REV Control
Signal (FWD=”L”/REV=”H”)
C-FG
Capstan Motor Rotation Detection
Pulse
C-POW-SW Capstan Power Switching Signal
C-ROTA
Color Phase Rotary Changeover
SIgnal
C-SYNC Composite Synchronized Pulse
CENTER Center Speaker Signal
CLKSEL Clock Select (GND)
COLOR-IN
SECAM or MESECAM Chroma
Video Input Signal at Super Impose
CTL (+) Playback/Record Control Signal (+)
CTL (-) Playback/Record Control Signal (-)
CTLAMPout To Monitor for CTL AMP Output
D-CONT Drum Motor Control Signal
D-PFG
Drum Motor Phase/Frequency
Generator
D-REC-H Delayed Record Signal
D-V- SYNC Dummy V-sync Output
DAVN-L VPS/PDC Data Receive = “L”
DISPLAY- ON/
OFF
DVD FIP ON/OFF Signal
DISPLAY-ACT
Tuner (AMP) VFD Indicating
Interrupt Input Signal
DISPLAY-CLK VFD Driver IC Control Clock
DISPLAY-
DATA
VFD Driver IC Control Data
DISPLAY-
DATA
VFD Driver IC Control Data
DISPLAY-ENA VFD Driver IC Chip Select Signal
DSC LED Control Signal
DVD A DVD Audio Signal
DVD LED “DVD” LED Signal Output
DVD PLAY DVD Play at High
DVD-16PIN SCART 16Pin DVD Control Signal
Signal Name Function
