ELECTRICAL PARTS LIST - POWER SUPPLY (AUDIO MODULE) & SPEAKER CONNECTION BOARDS
MISCELLANEOUS
4822 492 11735 SPRING TRANS
1200 4822 071 55002
!
FUSE T5A 250V
1203 4822 071 55002
!
FUSE T5A 250V
1204 9965 000 07786
!
FUSE T4A 250V
1205 9965 000 07786
!
FUSE T4A 250V
1263 4822 267 10733 FLEX SOCKET 4P VERT
1270 2422 025 14044
!
CONN SOCKET 6P
1303 2422 015 19885 SPEAKER SOCKET 12P
CAPACITORS
2000 5322 126 11583 10NF 10% 50V
2001 5322 126 11583 10NF 10% 50V
2002 5322 126 11583 10NF 10% 50V
2003 5322 126 11583 10NF 10% 50V
2004 5322 126 11583 10NF 10% 50V
2005 5322 126 11583 10NF 10% 50V
2006 5322 126 11583 10NF 10% 50V
2007 5322 126 11583 10NF 10% 50V
2008 5322 126 11583 10NF 10% 50V
2009 5322 126 11583 10NF 10% 50V
2010 5322 126 11583 10NF 10% 50V
2011 5322 126 11583 10NF 10% 50V
2200 4822 126 12785 47NF TUB 50V
2201 5322 124 40641 10UF 20% 100V
2202 4822 124 80231 47UF 20% 16V
2203 5322 121 42578 100NF 5% 250V
2204 5322 121 42578 100NF 5% 250V
2205 5322 121 42578 100NF 5% 250V
2206 4822 124 80563 4700UF 20% 35V
2207 4822 124 80563 4700UF 20% 35V
2208 5322 121 42661 330NF 5% 63V
2209 5322 121 42578 100NF 5% 250V
2211 4822 124 80563 4700UF 20% 35V
2212 5322 121 42386 100NF 5% 63V
2213 5322 121 42578 100NF 5% 250V
2215 2020 012 93745 10000UF 20% 16V
2217 2020 561 90365 100NF +80/-20% 50V
2218 4822 124 11947 10UF 20% 16V
2219 4822 124 81286 47UF 20% 16V
2220 4822 124 81286 47UF 20% 16V
2222 4822 124 12056 1000UF 20% 35V
2223 4822 124 12056 1000UF 20% 35V
2224 4822 124 41643 100UF 20% 16V
2225 4822 124 41643 100UF 20% 16V
2228 5322 124 40641 10UF 20% 100V
RESISTORS
3200 4822 116 52283 4K7 5% 0,5W
3201 4822 051 30272 2K7 5% 0,062W
3202 4822 051 30103 10K 5% 0,062W
3203 4822 051 30103 10K 5% 0,062W
3204 4822 117 12925 47K 1% 0.063W
3205 4822 051 30103 10K 5% 0,062W
3206 4822 051 30681 680R 5% 0,062W
3207 4822 051 30331 330R 5% 0,062W
3208 4822 051 30681 680R 5% 0,062W
3209 4822 051 30472 4K7 5% 0,062W
3216 4822 051 30331 330R 5% 0,062W
3217 4822 051 30682 6K8 5% 0,062W
3218 4822 051 30153 15K 5% 0,062W
3219 4822 051 30102 1K 5% 0,062W
3222 4822 051 30102 1K 5% 0,062W
3223 4822 117 13632 100K 1% 0.62W
3224 4822 116 83872 220R 5% 0,5W
3225 4822 052 10828
!
8R2 5% 0,33W
3226 4822 051 30471 470R 5% 0,062W
3227 4822 051 30102 1K 5% 0,062W
3229 4822 051 30472 4K7 5% 0,062W
3230 4822 051 30472 4K7 5% 0,062W
4210 4822 051 30008 0R JUMPER
4211 4822 051 30008 0R JUMPER
4212 4822 051 30008 0R JUMPER
DIODES
6200 4822 130 30621 1N4148
6201 3198 010 52790 DIO REG BZX79-B27 A COL A
6202 4822 130 31878 1N4003G
6203 4822 130 34382 BZX79-B8V2
6205 3198 010 52790 DIO REG BZX79-B27 A COL A
6208 4822 130 11397 BAS316
6209 4822 130 11397 BAS316
6211 4822 130 11139 GBU8D
6212 3198 010 10640 BRIDGE REC GBU4K COL
6214 4822 130 30621 1N4148
6215 4822 130 34174 BZX79-B4V7
6216 4822 130 34145 BZX79-B39
6217 4822 130 31878 1N4003G
6218 4822 130 34145 BZX79-B39
TRANSISTORS & INTEGRATED CIRCUITS
7200 9340 561 95127 FET POW BUK7535-55A (PHSE) L
7202 9340 561 95127 FET POW BUK7535-55A (PHSE) L
7203 5322 130 60159 BC846B
7205 4822 130 60373 BC856B
7206 4822 130 60373 BC856B
7207 5322 130 60159 BC846B
7208 4822 209 33575 L7812CP
7209 4822 209 12335 L4941
7210 4822 130 41246 BC327-25
Note: Only the parts mentioned in this list are normal service spare
parts.
MISCELLANEOUS
AC1001! 9965 000 20940
!
AC CORD /00/02
AC1001! 9965 000 20990
!
AC CORD /05
CN001B 9965 000 20924 CONNECTOR, 20P TUC-P20X-B1
CN1008 9965 000 20943 CONNECTOR, 3P B3P-VH
F1001! 9965 000 13786
!
FUSE T1.6A 250V
RL001! 9965 000 20945
!
POWER RELAY SDT-S-112LMR
SA1001! 9965 000 20946
!
SURGE ABSORBER PVR-10D471KB
SA1001! 9965 000 08602
!
SURGE ABSORBER CNR-10D471K
T001! 9965 000 19673
!
SW TRANSFORMER CSA-SW0274B
CAPACITORS
C013 9965 000 14852 ELCAP 10UF/50V M
C013 9965 000 19661 ELCAP 10UF/50V M
C014 9965 000 19662 ELCAP 470UF/25V M
C014 9965 000 19654 ELCAP 470UF/25V M
C017 9965 000 14857 ELCAP 1000UF/16V M
C018 9965 000 14862 ELCAP 470UF/6.3V M
C018 9965 000 19558 ELCAP 470UF/6.3V M
C019 9965 000 20941 FILM CAP.(P) 0.0015UF/100V J
C020 9965 000 14855 ELCAP 22UF/50V M
C020 9965 000 19549 ELCAP 22UF/50V M
C022 9965 000 19663 ELCAP 470UF/35V M
C022 9965 000 19655 ELCAP 470UF/35V M
C1001! 9965 000 14854
!
MET FILM CAP. 0.068UF/275V K
C1001! 9965 000 06521
!
METALLIZED FILM CAP. 0.068UF/250
C1003 4822 126 14142 0.01UF 500V
C1004 9965 000 13677 ELCAP 100UF/400V M
C1004 9965 000 20942 ELCAP 100UF/400V M
C1005 4822 126 14141 56PF 1KV
C1005 9965 000 06567 CERAMIC CAP. SL J 56PF/1KV
C1006! 9965 000 06522
!
SAFTY CAP. 2200PF/250V
C1006! 9965 000 11407
!
SAFETY CAPACITOR 2200PF
C1007 9965 000 19664 ELCAP 1000UF/6.3V M
C1018 4822 124 41584 100UF 20% 10V
C1018 9965 000 19666 ELCAP 100UF/10V M
C1032 9965 000 09762 ELCAP 220UF/6.3V M H7
C1032 9965 000 19554 ELCAP 10UF/16V M
C1033 9965 000 09752 ELCAP 1000UF/16V M
C1033 9965 000 09751 ELCAP 100UF/16V M
C1035 9965 000 19662 ELCAP 470UF/25V M
C1035 9965 000 19654 ELCAP 470UF/25V M
C1054 9965 000 14862 ELCAP 470UF/6.3V M
C1054 9965 000 19558 ELCAP 470UF/6.3V M
C1105 9965 000 15246 ELCAP 100UF/16V M
C1105 9965 000 09789 CHIP CAP CG J 68PF/50V
C1106 9965 000 19667 ELCAP 100UF/35V M
C1106 9965 000 19656 ELCAP 100UF/35V M
C1107 9965 000 09827 CHIP CAP CH J 100PF/50V
C1107 9965 000 19660 ELCAP 220UF/6.3V M
C1108 9965 000 14862 ELCAP 470UF/6.3V M
C1108 9965 000 19558 ELCAP 470UF/6.3V M
C1109 9965 000 09827 CHIP CAP CH J 100PF/50V
C1109 9965 000 19660 ELCAP 220UF/6.3V M
RESISTORS
R1001 9965 000 08653 CARBON RES. 1/2W K 5.6M OHM
R1001 9965 000 20944 GL GLAZE RES. 1/2W J 5.6MOHM
R1004 4822 053 11823
!
82K 5% 2W
R1004 4822 053 11823
!
82K 5% 2W
R1011 9965 000 19605
!
MET OXIDE RES. 1W J 1.3 OHM
R1011 9965 000 19606
!
MET OXIDE RES. 1W J 1.3 OHM
R1043 9965 000 19665
!
MET OXIDE RES. 1W J 2.7 OHM
R1043 9965 000 19607
!
MET OXIDE RES. 1W J 2.7 OHM
COILS & FILTERS
J922 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3
L013 9965 000 05627 CHOKE COIL 47UH-K
L013 9965 000 05702 CHOKE COIL 47UH-K
L1001 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3
L1002 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3
L1003! 9965 000 13005
!
LINE FILTER 50MH LF-4D-E503 OR
L1003! 9965 000 13005
!
LINE FILTER 50MH LF-4D-E503 OR
L1004 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3
L1009 9965 000 05627 CHOKE COIL 47UH-K
L1009 9965 000 05702 CHOKE COIL 47UH-K
L1010 9965 000 05627 CHOKE COIL 47UH-K
L1010 9965 000 05702 CHOKE COIL 47UH-K
L1011 9965 000 05627 CHOKE COIL 47UH-K
L1011 9965 000 05702 CHOKE COIL 47UH-K
L1012 9965 000 05627 CHOKE COIL 47UH-K
L1012 9965 000 05702 CHOKE COIL 47UH-K
DIODES
D013 4822 130 11654 BA158
D014 9965 000 19668 SCHOTTKY BARRIER DIODE SB390
D015 9965 000 08649 ZENER DZ-5.6BSCT265
D015 4822 130 10926 UZ5.6BSC
D016 4822 130 32715 SB340
D017 9965 000 15310 ZENER DZ-8.2BSAT265
D017 9965 000 05248 ZENER MTZJT-778.2A
D018 4822 130 11654 BA158
D019 9965 000 19669 RECTIFIER DIODE FR2 3
D1001 4822 130 31933 1N5061
D1002 4822 130 31933 1N5061
D1003 4822 130 31933 1N5061
D1004 4822 130 31933 1N5061
D1006 4822 130 30621 1N4148
D1006 4822 130 32778 1SS133
D1008 5322 130 81917 SB140
D1008 4822 130 80601 ERB81-004
D1011 5322 130 34979 BYV96E
D1011 4822 130 81244 ERA22-10
D1012 4822 130 30621 1N4148
ELECTRICAL PARTS LIST - POWER SUPPLY (FOR VCR/DVD) & JUNCTION-C CBAs
1-18-15 1-18-16
