1-6-2 E9515SNA
DVD-8PIN-IN
SCART 8Pin DVD Input Control
Signal
DVD-AUDIO DVD Audio Control Signal
DVD-B-OUT
DVD Component Video Signal
(blue)
DVD-G-OUT
DVD Component Video Signal
(green)
DVD-LED “DVD” LED Signal Output
DVD-P-
ON+12V
+12V at DVD Power-On Signal
DVD-P-
ON+3.3V
+3.3V at DVD Power-On Signal
DVD-P-
ON+5V
+5V at DVD Power-On Signal
DVD-PLAY DVD Playback Control Signal
DVD-POWER DVD Power Control Signal
DVD-
POWERMONI
TOR
DVD Power Monitor Signal
(P-off="H", P-on="L")
DVD-R-OUT
DVD Component Video Signal
(red)
DVD-VIDEO DVD Video Control Signal
END-S Tape End Position Detect Signal
EV+1.5V +3.3V Power Supply
EV+3.3V +3.3V Power Supply
EV+5V +5V Power Supply
F1
Filament Power Supply 1
F2
Filament Power Supply 2
FE-H GND Ground for Full Erase Head
FF/REW-L
CTL Frequency Characteristics
Switching Signal (FF/REW=”L”)
FIL-ON/OFF Filament ON/OFF Control Signal
FIP+5V
FIP IC Power Supply
FP-CLK
Clock Input
FP-DIN
Serial Data Input
FP-DOUT
Serial Data Output
FP-STB
Serial Interface Strobe
FSC-IN
[4.43MHz]
4.43MHz Clock Input
FTV-IN
Comparator Input of Video Signal
for Follow TV
H-A-COMP Head Amp Comparator Signal
H-A-SW Video Head Amp Switching Pulse
Signal Name Function
HDPH-DET Headphone Detecting Signal
HDPH-L/R
Headphone Left/Right Output
Signal
Hi-Fi-A Hi-Fi Audio Head
Hi-Fi-COM Hi-Fi Audio Head Common
Hi-Fi-H-SW Hi-Fi Audio Head Switching Pulse
HLF LPF Connected Terminal (Slicer)
IIC-BUS- SCL IIC BUS Control Clock
IIC-BUS- SDA IIC BUS Control Data
INPUT
SELECT
Input Select
JK1-8P-OUT SCART 8Pin Output Control Signal
KEY-1 Key Scan Input Signal 1
KEY-2 Key Scan Input Signal 2
LD-SW
Deck Mode Position Detector
Signal
LINE MUTE Audio Mute Control Signal
LM-FWD/REV Loading Motor Control Signal
LOAD-CONT
Load Power Supply Switching
Signal
LP LP
MOD-A Modulator Audio Output Signal
MOD-V Modulator Video Output Signal
N-A-PB Normal Audio Playback
N-A-REC Normal Audio Recording
OSC Oscillator Input
OSCin Clock Input for letter size
OSCout Clock Output for letter size
OSD-V-IN OSD Video Signal Input
OSD-V-OUT OSD Video Signal Output
OSDVcc OSDVcc
OSDVss OSDVss
OUTPUT-
SEL2
Output Select, “L”=VCR/Tuner,
“H”=DVD
OUTPUT-
SELECT
Output Select
P-DOWN-L
Power Voltage Down Detector
Signal
P-OFF-H Power Off at High
Signal Name Function
