Philips MX5100VR - Page 21

1-6-3 E9515SNA
P-OFF-H Power Off at High
P-ON+15V +15V at Power-On Signal
P-ON+44V +44V at Power-On Signal
P-ON+5V +5V at Power-On Signal
P-ON-H Power On Signal at High
P80/C P80/C Terminal
PB-H-OUT Playback Signal Output at High
PCM-DATA Pulse Code Modulation Data
PG-DELAY
Video Head Switching Pulse Signal
Adjusted Voltage
POW-SAF P-ON Power Detection Input Signal
POWER- LED “POWER” LED Signal Output
PWRCON Power Down
PWSW Data IN/OUT Signal
REC-LED “REC” LED Signal Output
REC-SAF-SW
Recording Safety SW Detect (With
Record tab=”L”/ With out Record
tab=”H”)
REMOTE-
DVD
DVD Remote Control Sensor
REMOTE-
VIDEO
Video Remote Control Sensor
RESET System Reset Signal (Reset=”L”)
RF-SW Video Head Switching Pulse
RGB-
THROUGH1
SCART 2 RGB Through Control
Signal
S-REEL Supply Reel Rotation Signal
SC2-IN Input Signal from Pin 8 of SCART2
SECAM-C-IN SECAM Chroma Signal Input
SECAM-FM-
OUT
SECAM FM Signal Output
SECAM-H SECAM Mode at High
SIF Source Input Format
SORROUND Surround Speaker Signal
SPDIF
Digital Audio Interface Format
Signal
ST-S Tape Start Position Detector Signal
STOP/EJECT Tape Stop/Eject Signal
SUB-
WOOFER
Sub Woofer Signal
Signal Name Function
T-REEL
Take Up Reel
Rotation Signal
TIMER LED “TIMER” LED Signal Output
TIMER+5V +5V at Timer
TIMER- LED “TIMER” LED Signal Output
TRICK-H
Special Playback = “H” in SECAM
Mode
TU-AUDIO Tuner Audio Input Signal
TU-VIDEO Tuner Video Input Signal
TUNER- LED
“TUNER” LED
Signal Output
TUNER-
POWER
Receiver Main Power Supply
Control Signal (OFF=“L”, ON=“H”)
V-COM Video Head Common
V-ENV Video Envelope Comparator Signal
V-IN Video Signal Input
V-OUT Video Signal Output
Vcc Vcc
VCR-LED “VCR” LED Signal Output
VIDEO Video Signal
VOL-A/B Volume Control Signal
VSS GND
XCin Sub Clock
XCout Sub Clock
Xin Main Clock Input
Xout Main Clock Input
