1-16-2 E9015PIN
38 IN
Xin Main Clock Input
-
39 OUT
Xout Main Clock Input
-
40 -
Vss Vss(GND)
-
41 OUT
INPUT
SELECT
Input Select
H/L
42 IN
DVD-
8PIN-IN
SCART 8Pin DVD
Input Control Signal
H/L
43 IN
CLKSEL Clock Select (GND)
L
44 IN
OSCin
Clock Input
for letter size
-
45 OUT
OSCout
Clock Output for
letter size
-
46 -
NUB Not Used
-
47 -
LP LP
-
48 IN
FSC-IN
[4.43MHz]
4.43MHz Clock
Input
-
49 -
OSDVss OSDVss
-
50 IN
OSD-V-IN
OSD Video Signal
Input
-
51 -
NU Not Used
-
52 OUT
OSD-V-
OUT
OSD Video Signal
Output
-
53 -
OSDVcc OSDVcc
-
54 -
HLF
LPF Connected
Terminal (Slicer)
-
55
A,B -
NU Not Used
-
CIN
COLOR-
IN
SECAM or
MESECAM Chroma
Video Input Signal
at Super Impose
Z/L
56 -
NU Not Used
-
57 -
NU Not Used
-
58 IN
C-SYNC
Composite
Synchronized Pulse
PULSE
59 OUT
8POUT-1 Control SCART 1
8Pin Level by using
8POUT-1 and
8POUT-2
H/L
60 OUT
8POUT-2
61
A,B
-
NU Not Used
-
CIN
SECAM-H
SECAM Mode at
High
H/L
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
Active
Level
62
OUT
TUNER-
POWER
Receiver Main
Power Supply
Control Signal
(OFF=“L”, ON=“H”)
H
63
OUT
DISPLAY-
ON/OFF
DVD FIP ON/OFF
Signal
H
64 IN
FTV-IN
Comparator Input of
Video Signal for
Follow TV
L/Hi-z
65
A,B -
NU Not Used
-
COUT
TRICK-H
Special Playback =
“H” in SECAM Mode
H
66 OUT
C-POW-
SW
Capstan Power
Switching Signal
H/L
67 OUT
P-ON-H
Power On Signal at
High
H
68 OUT
DISPLAY-
DATA
VFD Driver IC
Control Data
H/L
69 OUT
DISPLAY-
ENA
VFD Driver IC Chip
Enable Signal
H/L
70 OUT
DISPLAY-
CLK
VFD Driver IC
Control Clock
H/L
71 OUT
IIC-BUS-
SCL
IIC BUS Control
Clock
H/L
72
IN/
OUT
IIC-BUS-
SDA
IIC BUS Control
Data
H/L
73 OUT
P-OFF-H Power Off at High
H
74 OUT
OUTPUT-
SELECT
Output Select
H/L
75 IN
DVD-
POWERM
ONITOR
DVD Power Monitor
Signal (P-off="L",
P-on="H")
H/L
76 OUT
C-CONT
Capstan Motor
Control Signal
PWM
77 OUT
D-CONT
Drum Motor Control
Signal
PWM
78 OUT
C-F/R
Capstan Motor
FWD/REV Control
Signal (FWD=”L”/
REV=”H”)
H/L
79 IN
S-REEL
Supply Reel
Rotation Signal
PULSE
80 IN
T-REEL
Take Up Reel
Rotation Signal
PULSE
81 OUT
LM-FWD/
REV
Loading Motor
Control Signal
H/L/
Hi-z
82 OUT
LINE-
MUTE
Audio Mute Control
Signal
H
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
Active
Level
