1-18-1
MISCELLANEOUS
CN503 9965 000 05245 FE CONN.TOP 7P 07FE-BT-VK-N
CN1051 9965 000 19569 FMN CONN. SIDE 22P 22FMN-STRK
CN1601 9965 000 19570 FMN CONN., SIDE 18P 18FMN-STK
CN2001 9965 000 20915 FMN CONN TOP 4P 04FMN-BTRK
CN2020 9965 000 20916 FE CONN TOP 12P 12FE-BT-VK-N
JK752 4822 265 11659 RCA JACK(YELLOW) MSP-281V4-B
JK753 4822 265 11661 RCA JACK(WHITE) MSP-281V1-B
JK754 9965 000 00423 MSP-281V3-A RCA JACK(RED)
JK1405 9965 000 20921 PHONE JACK JY-6303*01-060
PS502 9965 000 12189 PHOTO INTERRUPTER RPI-302C70
RM2001 9965 000 10857 REMOTE RECEIVER
SW501 4822 276 13954 KSM0614B
SW501 4822 276 14127 SKQSAF001A
SW501 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SW506 9965 000 16625 LEAF SWITCH MXS01830MVP0
SW507 9965 000 16626 ROTARY MODE SWITCH SSS-50MD
SW507 9965 000 19591 ROTARY MODE SWITCH R8100245
SW603 4822 276 13954 KSM0614B
SW603 4822 276 14127 SKQSAF001A
SW603 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SW2021 4822 276 13954 KSM0614B
SW2021 4822 276 14127 SKQSAF001A
SW2021 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SW2022 4822 276 13954 KSM0614B
SW2022 4822 276 14127 SKQSAF001A
SW2022 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
X301 9965 000 05629 X’TAL 4.433619MHZ
X301 4822 242 10695 4 433 619 MHZ
X501 9965 000 12194 X’TAL 12.000MHZ
X502 9965 000 12288 X’TAL 32.768KHZ(20PPM)
X502 9965 000 19592 X’TAL 32.768KHZ(20PPM)
X2001 9965 000 19593 CER RES.(47PF) CSTLS4M G56-A0
CAPACITORS
C056 9965 000 14863 ELCAP 47UF/25V M
C056 9965 000 19553 ELCAP 47UF/25V M
C057 9965 000 09762 ELCAP 220UF/6.3V M H7
C057 9965 000 19554 ELCAP 10UF/16V M
C058 9965 000 19555 ELCAP 330UF/6.3V M
C058 9965 000 19556 ELCAP 330UF/6.3V M
C059 9965 000 09843 CAP(AX) SL J 56PF/50V
C059 9965 000 09844 CAP(AX) B J 1000PF/50V
C063 9965 000 15244 ELCAP 47UF/16V M
C063 9965 000 19557 ELCAP 47UF/16V M
C129 9965 000 15293 ELCAP 100UF/16V M H7
not for /02
C130 9965 000 19560 ELCAP 4.7UF/50V M H7 not for /02
C131 9965 000 19560 ELCAP 4.7UF/50V M H7 not for /02
C132 9965 000 19560 ELCAP 4.7UF/50V M H7 not for /02
C251 9965 000 15290 ELCAP 10UF/16V M H7
C254 9965 000 15291 ELCAP 1UF/50V M H7
C302 9965 000 15291 ELCAP 1UF/50V M H7
C305 9965 000 15291 ELCAP 1UF/50V M H7
C312 9965 000 15290 ELCAP 10UF/16V M H7
C313 9965 000 19561 ELCAP 1UF/50V M H7
C316 9965 000 15291 ELCAP 1UF/50V M H7
C328 9965 000 15292 ELCAP 47UF/6.3V M H7
C330 9965 000 15293 ELCAP 100UF/16V M H7
C331 4822 124 12052 220UF 20% 6,3V
C334 9965 000 15291 ELCAP 1UF/50V M H7
C335 9965 000 15295 ELCAP 100UF/6.3V H7
C340 9965 000 15291 ELCAP 1UF/50V M H7
C343 9965 000 15290 ELCAP 10UF/16V M H7
C344 9965 000 15296 ELCAP 4.7UF/25V M NP
C345 9965 000 15297 ELCAP 0.47UF/50V M H
C349 9965 000 15297 ELCAP 0.47UF/50V M H
C379 9965 000 15297 ELCAP 0.47UF/50V M H
/02
C384 9965 000 15301 ELCAP 2.2UF/50V M H /02
C402 9965 000 19548 FILM CAP.(P) 0.018UF/50V J
C403 9965 000 06523 CERAMIC CAP. B K 470PF/100V
C404 9965 000 09760 CHIP CAP F Z 0.1UF/50V
C405 9965 000 15292 ELCAP 47UF/6.3V M H7
C410 9965 000 15290 ELCAP 10UF/16V M H7
C412 9965 000 15299 ELCAP 33UF/6.3V M H7
C415 9965 000 15298 ELCAP 4.7UF/25V M H7
C417 9965 000 15300 ELCAP 22UF/6.3V M H7
C421 9965 000 15292 ELCAP 47UF/6.3V M H7
C452 9965 000 15290 ELCAP 10UF/16V M H7
C453 9965 000 15303 ELCAP 22UF/10V M H7
C456 9965 000 15290 ELCAP 10UF/16V M H7
C457 9965 000 15298 ELCAP 4.7UF/25V M H7
C463 9965 000 15303 ELCAP 22UF/10V M H7
C465 9965 000 15290 ELCAP 10UF/16V M H7
C468 4822 124 12052 220UF 20% 6,3V
C469 9965 000 15303 ELCAP 22UF/10V M H7
C472 9965 000 15298 ELCAP 4.7UF/25V M H7
C473 9965 000 15290 ELCAP 10UF/16V M H7
C476 9965 000 15300 ELCAP 22UF/6.3V M H7
C479 9965 000 15290 ELCAP 10UF/16V M H7
C480 9965 000 15298 ELCAP 4.7UF/25V M H7
C481 9965 000 15298 ELCAP 4.7UF/25V M H7
C483 9965 000 15298 ELCAP 4.7UF/25V M H7
C484 9965 000 15298 ELCAP 4.7UF/25V M H7
C485 9965 000 15290 ELCAP 10UF/16V M H7
C487 9965 000 15302 ELCAP 47UF/16V M H7
C506 4822 124 12052 220UF 20% 6,3V
C516 9965 000 15300 ELCAP 22UF/6.3V M H7
C518 9965 000 15300 ELCAP 22UF/6.3V M H7
C521 9965 000 15300 ELCAP 22UF/6.3V M H7
C534 9965 000 15292 ELCAP 47UF/6.3V M H7
C549 9965 000 15291 ELCAP 1UF/50V M H7
C550 9965 000 15295 ELCAP 100UF/6.3V H7
C553 9965 000 15303 ELCAP 22UF/10V M H7
C611 9965 000 14855 ELCAP 22UF/50V M
C611 9965 000 19549 ELCAP 22UF/50V M
C615 9965 000 15295 ELCAP 100UF/6.3V H7
C632 9965 000 19562 ELCAP 1UF/50V M H7 NP
C633 9965 000 15291 ELCAP 1UF/50V M H7
C636 9965 000 15298 ELCAP 4.7UF/25V M H7
C637 9965 000 15292 ELCAP 47UF/6.3V M H7
C752 9965 000 19563 ELCAP 47UF/10V M H7
C753 9965 000 09821 CHIP CAP B K 0.022UF/25V
C754 9965 000 09821 CHIP CAP B K 0.022UF/25V
C757 9965 000 20914 ELCAP 47UF/6.3V M H7
C761 9965 000 19560 ELCAP 4.7UF/50V M H7
C762 9965 000 19560 ELCAP 4.7UF/50V M H7
C779 9965 000 19561 ELCAP 1UF/50V M H7
C780 9965 000 15290 ELCAP 10UF/16V M H7
C782 9965 000 15291 ELCAP 1UF/50V M H7
C1061 9965 000 19566 ELCAP 2200UF/6.3V M
C1201 9965 000 15290 ELCAP 10UF/16V M H7
C1202 9965 000 15290 ELCAP 10UF/16V M H7
C1221 9965 000 15290 ELCAP 10UF/16V M H7
C1222 9965 000 09762 ELCAP 220UF/6.3V M H7
C1222 9965 000 19554 ELCAP 10UF/16V M
C1247 9965 000 14853 ELCAP 470UF/16V M
C1247 9965 000 19567 ELCAP 470UF/16V M
C1249 9965 000 15302 ELCAP 47UF/16V M H7
C1393 9965 000 14862 ELCAP 470UF/6.3V M
C1393 9965 000 19558 ELCAP 470UF/6.3V M
C1394 9965 000 15292 ELCAP 47UF/6.3V M H7
C1442 9965 000 14862 ELCAP 470UF/6.3V M
C1442 9965 000 19558 ELCAP 470UF/6.3V M
C1445 9965 000 14862 ELCAP 470UF/6.3V M
C1445 9965 000 19558 ELCAP 470UF/6.3V M
C1461 9965 000 15289 ELCAP 1UF/50V M
C1461 9965 000 19559 ELCAP 1UF/50V M
C1462 9965 000 14862 ELCAP 470UF/6.3V M
C1462 9965 000 19558 ELCAP 470UF/6.3V M
C1471 9965 000 15289 ELCAP 1UF/50V M
C1471 9965 000 19559 ELCAP 1UF/50V M
C1481 9965 000 15289 ELCAP 1UF/50V M
C1481 9965 000 19559 ELCAP 1UF/50V M
C1482 9965 000 14862 ELCAP 470UF/6.3V M
C1482 9965 000 19558 ELCAP 470UF/6.3V M
C1532 9965 000 15300 ELCAP 22UF/6.3V M H7
C2004 9965 000 15295 ELCAP 100UF/6.3V H7
RESISTORS
R304 9965 000 08652 INDUCTOR 5.6UH-K-26T
R304 9965 000 19589 CHIP IND. HK1608 18NJ-T
R309 9965 000 08652 INDUCTOR 5.6UH-K-26T
R309 9965 000 19589 CHIP IND. HK1608 18NJ-T
VR501 9965 000 05260 CARBON P.O.T. 100K OHM B
COILS & FILTERS
L052 9965 000 05627 CHOKE COIL 47UH-K
L052 9965 000 05702 CHOKE COIL 47UH-K
L053 9965 000 13681 INDUCTOR 100UH-J-5FT
L251 9965 000 08652 INDUCTOR 5.6UH-K-26T
L302 4822 157 10649 100UH
L401 9965 000 05627 CHOKE COIL 47UH-K
L401 9965 000 05702 CHOKE COIL 47UH-K
L402 9965 000 05705 INDUCTOR 47UH-K-5FT
L451 9965 000 05705 INDUCTOR 47UH-K-5FT
L452 9965 000 16621 INDUCTOR 27UH-K-5FT
L501 4822 157 10649 100UH
L503 9965 000 08629 INDUCTOR 1.8UH-K-26T
L1521 9965 000 05627 CHOKE COIL 47UH-K
L1521 9965 000 05702 CHOKE COIL 47UH-K
L2001 4822 157 10649 100UH
L2002 4822 157 11511 15UH-K-26T
DIODES
D051 4822 130 31933 1N5061
D052 4822 130 31933 1N5061
D053 4822 130 31933 1N5061
D054 9965 000 09283 ZENER DZ-10BSBT265
D054 4822 130 80998 MTZJ10C
D056 9965 000 09183 ZENER DZ-33BSDT265
D056 4822 130 81729 MTZJ33D
D057 4822 130 31933 1N5061
D301 4822 130 30621 1N4148
D301 4822 130 32778 1SS133
D370 4822 130 30621 1N4148
/02
D370 4822 130 32778 1SS133 /02
D501* 9965 000 08621 LED(RED) 204HD/E
D501* 4822 130 82978 LTL-16KPE-P
D504* 9965 000 08621 LED(RED) 204HD/E
D504* 4822 130 82978 LTL-16KPE-P
* Note: If any of the LED set (D501 & D504) has to be replaced, both the
LEDs must be replaced together.
D510 4822 130 30621 1N4148
D510 4822 130 32778 1SS133
D511 9965 000 15309 ZENER DZ-7.5BSAT265
D511 4822 130 10094 UZ7.5BSA
D512 4822 130 30621 1N4148
D512 4822 130 32778 1SS133
D555 9965 000 19572 LED MIE-534A2
D555 9965 000 05250 LED SIR-563ST3F P
D555 9965 000 05648 LED SIR-563ST3F Q
D751 9965 000 15310 ZENER DZ-8.2BSAT265
D751 9965 000 05248 ZENER MTZJT-778.2A
D1052 5322 130 81917 SB140
D1052 4822 130 80601 ERB81-004
D1053 4822 130 31933 1N5061
D1054 4822 130 31933 1N5061
D1055 4822 130 31933 1N5061
D1057 4822 130 31933 1N5061
ELECTRICAL PARTS LIST - MAIN CBA ELECTRICAL PARTS LIST - MAIN CBA
1-18-2
