Philips MX5100VR - Page 121

JACK-A & JUNCTION-A CBA
MISCELLANEOUS
CN2120 9965 000 20932 CONNECTOR, 18P TUC-P18X-B1
JK101 9965 000 20716 RGB CONNECTOR MRC-021V-03
CAPACITORS
C104 9965 000 15246 ELCAP 100UF/16V M
C104 9965 000 09789 CHIP CAP CG J 68PF/50V
C107 9965 000 14862 ELCAP 470UF/6.3V M
C107 9965 000 19558 ELCAP 470UF/6.3V M
C117 9965 000 15289 ELCAP 1UF/50V M
C117 9965 000 19559 ELCAP 1UF/50V M
C127 9965 000 09762 ELCAP 220UF/6.3V M H7
C127 9965 000 19554 ELCAP 10UF/16V M
DIODES
D103 9965 000 12178 ZENER DZ-11BSAT265
D103 9965 000 19571 ZENER MTZJT-7711A
D104 9965 000 12178 ZENER DZ-11BSAT265
D104 9965 000 19571 ZENER MTZJT-7711A
D106 9965 000 12178 ZENER DZ-11BSAT265
D106 9965 000 19571 ZENER MTZJT-7711A
D108 9965 000 12178 ZENER DZ-11BSAT265
D108 9965 000 19571 ZENER MTZJT-7711A
D109 9965 000 12178 ZENER DZ-11BSAT265
D109 9965 000 19571 ZENER MTZJT-7711A
D110 9965 000 12178 ZENER DZ-11BSAT265
D110 9965 000 19571 ZENER MTZJT-7711A
D115 9965 000 12178 ZENER DZ-11BSAT265
D115 9965 000 19571 ZENER MTZJT-7711A
D118 9965 000 12178 ZENER DZ-11BSAT265
D118 9965 000 19571 ZENER MTZJT-7711A
D119 9965 000 12178 ZENER DZ-11BSAT265
D119 9965 000 19571 ZENER MTZJT-7711A
D121 9965 000 12178 ZENER DZ-11BSAT265
D121 9965 000 19571 ZENER MTZJT-7711A
COILS & FILTERS
L101 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3
TRANSISTORS
Q104 4822 130 42959 2SA1015Y
Q104 4822 130 11101 2SA1015GR
JACK-B & JUNCTION-B CBA
MISCELLANEOUS
CN2115 9965 000 20933 CONNECTOR, 10P TUC-P10X-B1
JK1402 9965 000 20716 RGB CONNECTOR MRC-021V-03
CAPACITORS
C102 9965 000 15289 ELCAP 1UF/50V M
LED CBA
MISCELLANEOUS
CN651 9965 000 05245 FE CONN.TOP 7P 07FE-BT-VK-N
SW651 4822 276 13954 KSM0614B
SW651 4822 276 14127 SKQSAF001A
SW651 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SW652 4822 276 13954 KSM0614B
SW652 4822 276 14127 SKQSAF001A
SW652 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
SW653 4822 276 13954 KSM0614B
SW653 4822 276 14127 SKQSAF001A
SW653 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
DIODES
D651* 9965 000 08621 LED(RED) 204HD/E
D651* 4822 130 82978 LTL-16KPE-P
D652* 9965 000 08621 LED(RED) 204HD/E
D652* 4822 130 82978 LTL-16KPE-P
D653* 9965 000 08621 LED(RED) 204HD/E
D653* 4822 130 82978 LTL-16KPE-P
D654* 9965 000 08621 LED(RED) 204HD/E
D654* 4822 130 82978 LTL-16KPE-P
* Note: If any of the LED set (D651 - D654) has to be replaced, all the four
LEDs must be replaced together.
FRONT CBA
MISCELLANEOUS
CN2015 9965 000 05246 FE CONN.TOP 9P 09FE-BT-VK-N
SW502 4822 276 13954 KSM0614B
SW502 4822 276 14127 SKQSAF001A
SW502 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
VR502 9965 000 20930 ROTARY ENCODER EC12E2430803
DIODES
D2011* 9965 000 08623 LED(GREEN) 204-10GD/S957
D2011* 4822 130 10685 LTL4231N-001
D2012* 9965 000 08623 LED(GREEN) 204-10GD/S957
D2012* 4822 130 10685 LTL4231N-001
D2013* 9965 000 08623 LED(GREEN) 204-10GD/S957
D2013* 4822 130 10685 LTL4231N-001
D2014* 9965 000 08623 LED(GREEN) 204-10GD/S957
D2014* 4822 130 10685 LTL4231N-001
D2015* 9965 000 08623 LED(GREEN) 204-10GD/S957
D2015* 4822 130 10685 LTL4231N-001
* Note: If any of the LED set (D2011 - D2015) has to be replaced, all the
five LEDs must be replaced together.
ELECTRICAL PARTS LIST - JACK-A & JUNCTION-A, JACK-B & JUNCTION-B and JACK-C CBAs
C102 9965 000 19559 ELCAP 1UF/50V M
C108 9965 000 14862 ELCAP 470UF/6.3V M
C108 9965 000 19558 ELCAP 470UF/6.3V M
COILS & FILTERS
L102 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3
DIODES
D101 9965 000 12178 ZENER DZ-11BSAT265
D101 9965 000 19571 ZENER MTZJT-7711A
D102 9965 000 12178 ZENER DZ-11BSAT265
D102 9965 000 19571 ZENER MTZJT-7711A
D105 9965 000 12178 ZENER DZ-11BSAT265
D105 9965 000 19571 ZENER MTZJT-7711A
D107 9965 000 12178 ZENER DZ-11BSAT265
D107 9965 000 19571 ZENER MTZJT-7711A
D112 9965 000 12178 ZENER DZ-11BSAT265
D112 9965 000 19571 ZENER MTZJT-7711A
D113 9965 000 12178 ZENER DZ-11BSAT265
D113 9965 000 19571 ZENER MTZJT-7711A
TRANSISTORS
Q103 4822 130 42959 2SA1015Y
Q103 4822 130 11101 2SA1015GR
JACK-C CBA
MISCELLANEOUS
CN1202 9965 000 05247 CONNECTOR BASE 4P TUC-P04P-B1
JK1202 9965 000 15322 RCA JACK(BLACK) MSP-281V2-B
COILS & FILTERS
L1251 9965 000 15331 INDUCTOR 0.47UH-K-26T
L1351 4822 157 10649 100UH
TRANSISTORS
Q1351 4822 130 10103 KTC3199Y
Q1351 9965 000 10994 2SC3199-GR/KTC3199-GR
Q1351 4822 130 11647 2SC2785J
Q1351 9965 000 19583 TRANSISTOR 2SC2785(H)
Q1351 9965 000 05643 TRANSISTOR 2SC2785(F)
Q1351 9965 000 09882 TRANSISTOR BN1L4M-T
Q1351 4822 130 41306 2SC1815GR
Note: Only the parts mentioned in this list are normal service spare
parts.
ELECTRICAL PARTS LIST - LED, FRONT, AFV, SENSOR and DVD OPEN/CLOSE CBAs
AFV CBA
MISCELLANEOUS
CN1 4822 265 11267 ANGLE PIN HEADER 9P
X1 9965 000 12200 X’TAL 18.432MHZ
CAPACITORS
C12 9965 000 14891 ELCAP 10UF/16V M H7
C15 9965 000 14891 ELCAP 10UF/16V M H7
C16 9965 000 14891 ELCAP 10UF/16V M H7
C20 9965 000 14892 ELCAP 3.3UF/50V M H7
C22 9965 000 14891 ELCAP 10UF/16V M H7
C24 9965 000 14893 ELCAP 0.22UF/50V M H
COILS & FILTERS
L1 4822 157 10889 10UH
L3 4822 157 11318 18UH 10%
L4 4822 157 10889 10UH
DIODES
D2 4822 130 30621 1N4148
D2 4822 130 32778 1SS133
INTEGRATED CIRCUITS
IC1 9965 000 14760 AUD UP MSP3417G-QG-B8-V3
IC1 9965 000 14760 AUD UP MSP3417G-QG-B8-V3
SENSOR CBA
9965 000 20894 SENSOR CBA (COMPLETE ASSY)
Q503 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12
Q503 9965 000 18096 PHOTO TRANSISTOR MID-32A22
Q503 9965 000 20922 PHOTO TRANSISTOR MID-32A22F
Q504 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12
Q504 9965 000 18096 PHOTO TRANSISTOR MID-32A22
Q504 9965 000 20922 PHOTO TRANSISTOR MID-32A22F
DVD OPEN/CLOSE CBA
SW2020 4822 276 13954 KSM0614B
SW2020 4822 276 14127 SKQSAF001A
SW2020 9965 000 19590 TACT SWITCH TC-1104(H=9.5)
Note: Only the parts mentioned in this list are normal service spare
parts.
