Philips MX5100VR - MECHANICAL PARTS LIST; Main Assembly Parts List

1-20-1
MECHANICAL PARTS LIST - MAIN ASSEMBLY + ACCESSORIES
9965 000 20891 DVD MAIN CBA UNIT /00/05
9965 000 20960 DVD MAIN CBA UNIT /02
9965 000 20894 SENSOR CBA
1B1 9965 000 19477 DECK ASSEMBLY CZD012/VM17E0
1B2 9965 000 19478 DVD MECHA 0838 VCDVM040
2B1 9965 000 20865 DECK PEDESTAL-1 E9000UD
2B6 9965 000 20866 DECK PEDESTAL-2 E9000UD
2B7 9965 000 20867 DECK PEDESTAL-3 E9000UD
2B22 9965 000 20868 PLATE, EARTH(PB) E9015ED
2B30 9965 000 20869 SPRING, KNOB E9000UD
2B46 9965 000 12173 ROHM HOLDER H7770JD
2B53 9965 000 20926 PLATE, GROUND(21PIN) H9500ED
A1X 9965 000 20861 FRONT ASSEMBLY E9015ED /00
A1X 9965 000 20958 FRONT ASSEMBLY E9017FD /02
A1X 9965 000 20976 FRONT ASSEMBLY E9016BD /05
A6 9965 000 20862 KNOB, VOLUME E9010UD
A34 9965 000 20863 FOOT K7010UA
A37 9965 000 20864 FAN COVER E9000UD
FN1 9965 000 20879 DC BRUSHLESS FAN
JW011 9965 000 20882 FFC CABLE, 22P FFC/P1.00/200
JW012 9965 000 20883 FFC CABLE, 18P FFC/P1.00/160
JW013 9965 000 20884 FFC CABLE, 7P FFC/P1.25/80
JW014 9965 000 20889 FFC CABLE, 20P FFC/P1.00/60
JW015 9965 000 20885 FFC CABLE, 12P FFC/P1.25/300
JW016 9965 000 20886 FFC CABLE, 9P FFC/P1.25/300
JW017 9965 000 20887 FFC CABLE, 9P FFC/P1.25/190
JW018 9965 000 20890 FFC CABLE, 13P FFC/P1.25/240
JW019 9965 000 20888 FFC CABLE, 4P FFC/P1.00/100
JW061 9965 000 20881 FFC CABLE, 8P FFC/P1.25/150
8013 3139 111 02651 FLEX CABLE 10P/100/10P AD
8014 3139 111 02651 FLEX CABLE 10P/100/10P AD
8016 3139 110 36140 FLEX CABLE 04P/180/04P AD
PT1 9965 000 20878
!
POWER TRANSFORMER
X1 9965 000 20870 REMOTE CONTROL 842/CDVR040
X3 4822 320 50377 CONNECT. CABLE PAL
X3 9965 000 17134 RF CABLE CC1001020012010
X6 9965 000 14782 SCART CABLE 1.5M CE1013020085710
X49 9965 000 20872 AM LOOP ANTENNA LAN-006
X50 9965 000 20873 FM ANTENNA CABLE
X20! 9965 000 20871 OWNER’S MANUAL E9015ED /00
X20! 9965 000 20959 OWNER’S MANUAL E9017FD /02
X20! 9965 000 20977 OWNER’S MANUAL E9016BD /05
LS 9965 000 20880 SATELLITE LS PACK + SUBWOOFER
Note: Only the parts mentioned in this list are normal service spare
parts.
9A 9965 000 21037 FRONT LS BOX LEFT
9B 9965 000 21038 FRONT LS BOX RIGHT
10A 9965 000 21039 REAR LS BOX LEFT
10B 9965 000 21040 REAR LS BOX RIGHT
32 9965 000 21041 CENTER LS BOX
34 9965 000 17045 FRONT GRILLE ASSY CENTER SPK
37 9965 000 17046 PHILIPS LOGO
51 9965 000 17047 KEYHOLE BRACKET PACK SET
60 9965 000 21042 SUBWOOFER BOX
69 9965 000 17048 FRONT GRILLE ASSY SUBWOOFER
70 9965 000 17046 PHILIPS LOGO
Note: Only the parts mentioned in this list are normal service spare
parts.
ELECTRICAL PARTS LIST - LOUDSPEAKER BREAKDOWN
