2-4-2 H9520DA
(1): Follow steps in sequence. When reassembling, follow the steps in reverse order.
These numbers are also used as identification (location) No. of parts in the figures.
(2): Indicates the part to start disassembling with in order to disassemble the part in column (1).
(3): Name of the part
(4): Location of the part: T=Top B=Bottom R=Right L=Left
(5): Figure Number
(6): Identification of parts to be removed, unhooked, unlocked, released, unplugged, unclamped, or desoldered.
P=Spring, W=Washer, C=Cut Washer, S=Screw, *=Unhook, Unlock, Release, Unplug, or Desolder
e.g., 2(L-2) = two Locking Tabs (L-2).
(7): Adjustment Information for Installation
(+):Refer to Deck Exploded Views for lubrication.
.
[34] [26]
Loading Arm (SP)
Assembly
B DM2,DM14
(+)Refer to Alignment
Sec.Pg.2-4-8
[35] [34]
Loading Arm (TU)
Assembly
B DM2,DM14
(+)Refer to Alignment
Sec.Pg.2-4-8
[36] [16],[26]
M Brake (TU) Assembly
(HI)
T DM1,DM15
[37] [2],[26]
M Brake (SP) Assembly
(HI)
T DM1,DM15 *(P-6)
[38] [37] Tension Lever Assembly T DM1,DM15
[39] [38] T Lever Holder T DM15 *(L-10)
[40] [40] M Gear (HI) T DM1,DM15 (C-6)
[41] [15],[40]
Sensor Gear (HI) T DM1,DM15 (C-7)
[42] [36],[40] Reel T T DM1,DM15
[43] [38] Reel S T DM1,DM15
[44] [34],[38]
Moving Guide S
Preparation
T DM1,DM16
[45] [35]
Moving Guide T
Preparation
T DM1,DM16
[46] [19] TG Post Assembly T DM1,DM16 *(L-11)
[47] [27] Rack Assembly R DM17
(+)Refer to Alignment
Sec.Pg.2-4-8
[48] [47] F Door Opener R DM17
[49] [49] Cleaner Assembly T DM1,DM6
[50] [49] CL Post T DM6 *(L-12)
↓
(1)
↓
(2)
↓
(3)
↓
(4)
↓
(5)
↓
(6)
↓
(7)
STEP
/LOC.
No.
START-
ING
No.
PART
REMOVAL INSTALLATION
Fig. No.
REMOVE/*UNHOOK/
UNLOCK/RELEASE/
UNPLUG/DESOLDER
ADJUSTMENT
CONDITION
