1-8-4 E9015DC
[17] Deck Assembly
(S-21)
Main CBA
FE Head
Cylinder
Assembly
Cylinder
Shield
AC Head
Assembly
(S-22)
(S-20)
LD-SW
Pin
Hole
Hole
Shaft
Cam Gear
Main CBA
[17] Deck Assembly
Main CBA
SW507
LD-SW
Pin
BOTTOM VIEW
Lead connections of Deck Assembly and Main CBA
Desolder
Desolder
Desolder
From
FE Head
From
Cylinder
Assembly
From
AC Head
Assembly
Lead with
white stripe
Lead with
blue stripe
From
Capstan
Motor
Assembly
Non Printing side
Fig. D9
