Philips MX5100VR - Page 69

1-12-49 1-12-50
DAC Schematic Diagram Parts Location Guide
Ref No. Position Ref No. Position Ref No. Position Ref No. Position
Q7308 E-3 R7207 B-3 R7402 C-2 R7508 C-1
Q7401 D-3 R7208 B-2 R7405 C-3 R7509 C-2
Q7402 D-2 R7209 B-1 R7406 C-2 R7510 C-1
Q7404 E-2 R7301 C-4 R7407 C-3 R7511 C-1
Q7405 E-3 R7302 C-3 R7408 C-2 R7512 C-1
Q7501 D-1 R7305 C-4 R7409 C-3 R7513 D-2
Q7502 D-1 R7306 C-3 R7410 C-2 R7514 D-1
Q7504 E-1 R7307 C-4 R7411 C-2 R7515 D-2
Q7505 E-1 R7308 C-3 R7412 C-2 R7516 D-1
Q7506 E-4 R7309 C-4 R7413 D-3 R7517 E-2
Q7507 E-4 R7310 C-4 R7414 D-2 R7518 E-1
R7311 C-4 R7415 D-3 R7519 E-1
JC14 A-2 R7312 C-4 R7416 D-2 R7520 E-1
JC15 A-2 R7313 D-4 R7417 E-3 R7521 D-1
JC16 A-1 R7314 D-3 R7418 E-2 R7522 D-1
JC17 A-1 R7317 E-4 R7419 E-3 R7523 D-2
JC18 A-1 R7319 D-4 R7420 E-2 R7524 D-1
R7102 A-2 R7320 D-4 R7421 D-3 R7525 D-1
R7103 A-2 R7322 E-4 R7422 D-2 R7526 D-1
R7104 A-2 R7329 E-4 R7423 D-3 R7541 C-1
R7105 A-1 R7330 E-3 R7424 D-2 R7544 C-2
R7106 A-1 R7333 D-4 R7425 D-2 R7548 E-4
R7107 A-1 R7334 D-3 R7426 D-2 R7600 E-3
R7108 A-1 R7335 D-4 R7441 C-2 R7601 E-3
R7119 A-1 R7336 D-3 R7444 C-3
R7123 A-3 R7337 D-4 R7501 C-2
R7124 A-3 R7339 D-3 R7502 C-1
R7201 B-3 R7341 C-4 R7505 C-2
R7203 B-2 R7344 C-4 R7506 C-1
R7205 B-1 R7401 C-3 R7507 C-2
RESISTORS
RESISTORSTRANSISTORS RESISTORS RESISTORS
Ref No. Position Ref No. Position Ref No. Position
C7103 E-4 C7341 C-4 C7543 C-2
C7105 E-4 C7342 C-4 C7544 C-2
C7107 A-4 C7343 C-4 C7548 A-1
C7109 E-4 C7344 C-4
C7111 A-4 C7401 C-3 CN7102 A-2
C7201 C-3 C7402 C-2 CN7103 F-2
C7202 C-3 C7405 C-3 CN7105 F-4
C7203 B-3 C7406 C-2
C7204 B-3 C7407 D-3 IC7201 B-4
C7205 C-4 C7408 D-2 IC7202 B-3
C7206 C-2 C7409 D-3 IC7203 B-1
C7207 C-2 C7410 D-2 IC7301 D-4
C7208 B-2 C7411 D-3 IC7402 D-3
C7209 B-2 C7412 D-2 IC7501 D-1
C7210 C-3 C7441 C-2
C7211 C-1 C7442 C-2 L7101 F-4
C7212 C-1 C7443 C-3 L7102 F-4
C7213 B-1 C7444 C-3 L7103 A-4
C7214 B-1 C7501 C-2 L7104 E-4
C7216 C-2 C7502 C-1 L7105 B-4
C7301 C-4 C7505 C-2 L7201 C-3
C7302 C-3 C7506 C-1 L7202 B-3
C7305 C-4 C7507 D-2 L7203 C-2
C7306 C-3 C7508 D-1 L7204 B-2
C7307 D-4 C7509 D-2 L7205 C-1
C7308 D-3 C7510 D-1 L7206 B-1
C7309 D-4 C7511 D-2
C7310 D-4 C7512 D-1 Q7301 D-4
C7313 D-4 C7541 C-1 Q7302 D-3
C7314 D-3 C7542 C-1 Q7305 E-4
TRANSISTORS
COILS
ICS
CONNECTORS
CAPACITORSCAPACITORS CAPACITORS
