9.2. PARTS LIST
NOTE:
1. When ordering replacement part(s), please use part number(s) shown in this part list.
Do not use description of the part.
2. Important safety notice:
Components identified by
mark have special characteristics important for safety.
When replacing any of these components, use only manufacture’s specified parts.
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
1 F00064W70AP CAUTION LABEL 1 SD681S,SN671S,SN661S,SA661S,SA651S
1 F00069660AP CAUTION LABEL 1 SN651B,SN651W,SA631B,SA631W
2 F21559Y10QP OVEN STICKY PAPER 1
3 F00339Y00AP FUSE LABEL 1
4 F10019Y00AP BASE 1
5 F10089W40HPS RUBBER FOOT 2
6 F10099Y00SAP CABINET BODY (U) 1 SD681S,SN671S,SN661S,,SA661S,SA651S
6 F10099Y00BAP CABINET BODY (U) 1 SN651B,SA631B
6 F10099Y00HAP CABINET BODY (U) 1 SN651W,SA631W
7 F200A9Y00HAP OVEN (U) 1 SD681S,SN671S,SN661S,SN651B,SN651W
7 F200A9Y10HAP OVEN (U) 1 SA661S,SA651S,SA631B,SA631W
8 F20559Y00AP COVER 1
9 F21319Y00AP PULLY SHAFT 1
11 F290D6W50XP ROLLER RING (U) 1
12 F30209Y00AP DOOR HOOK 1
13 F11619Y00AP REINFORCEMENT BRACKET 1
17 F400A9Y10AP FAN MOTOR 1 AC120V,SINGLE PHASE,60Hz
18 F40089Y00AP FAN BLADE 1
19 F40259Y00AP AIR GUIDE A 1
20 F41449Y00AP ORIFICE 1
21 J607S4T00AP STEAM SENSOR 1 SD681S,SN671S,SN661S,SN651B,SN651W
22 F64499Y00AP SENSOR COVER A 1 SD681S,SN671S,SN661S,SN651B,SN651W
24 F64508660AP SENSOR COVER B 1 SD681S,SN671S,SN661S,SN651B,SN651W
25 F65439Y00AP SENSOR COVER C 1 SD681S,SN671S,SN661S,SN651B,SN651W
26 F61425U30XN MICRO SWITCH 1 (PRIMARY INTERLOCK SWITCH)
27 F61415U30XN MICRO SWITCH 1 (SECONDARY INTERLOCK SWITCH)
28 F61456N60AP THERMAL CUTOUT 1
29 F612E9Y00AP INCANDESCENT LAMP (U) 1
30 F61785U30XN MICRO SWITCH 1 (MONITOR SWITCH)
31 F606Y8X00AP H.V.INVERTER (U) 1
32 2M261-M39R MAGNETRON 1
33 F62308F00AP FUSE 1
35 F66629Y00AP GROUNDING PLATE 1
36 F63265G60AP TURNTABLE MOTOR 1
37 F900C9Y00AP AC CORD W/PLUG 1 SD681S,SN671S,SN661S,SA661S,SA651S
37 F900C4T00AP AC CORD W/PLUG 1 SN651B,SN651W,SA631B,SA631W
38 F607X9S00CP NOISE FILTER 1
39 F11409W00XP STOPPER 2
40 F30069Y00AP HINGE A 1
41 XTWFA4+12T SCREW 2 FOR MAGNETRON
43 XTTBFE4T10A0 SCREW 4 FOR CABINET BODY
44 XTWFA4+12LR SCREW 3 FOR HINGE A
45 F65859Y00AP INVERTER BRACKET 1
46 F03349Y40AP MENU LABEL 1 SD681S
46 F03349Y00AP MENU LABEL 1 SN671S,SN661S,SN651B,SN651W
46 F03349Y10AP MENU LABEL 1 SA661S,SA651S,SA631B,SA631W
48 F00067C50AP CAUTION LABEL 1
30
NN-SD681S / NN-SN671S / NN-SN661S / NN-SA661S / NN-SA651S / NN-SN651B / NN-SN651W / NN-SA631B / NN-SA631W
