10.3. PARTS LIST
10.3.1. NN-SD681S
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ210 L0DDEA000014 BUZZER 1 2.0KHz
C10 F2A1H471B575 AL CHEM CAPACITOR 1 470µF/50V
C11 F2A1C220B624 AL CHEM CAPACITOR 1 22µF/16V
C482 F2A1H1R0B574 AL CHEM CAPACITOR 1 1µF/50V
C483 F2A1HR47B574 AL CHEM CAPACITOR 1 0.47µF/50V
C485 F2A1H2R2B574 AL CHEM CAPACITOR 1 2.2µF/50V
DISP110 L5AYAYY00101 LCD 1
DISP HOLDER F66175W00AP LCD HOLDER 1
F67525E40XN DIFFUSION SHEET 1
D40,D41,D190,D191,D221,D227,
D228,D230
B0AACK000004 DIODE 8
D10-D13 B0EAKT000025 DIODE 4
IC1 MN69F009AD1 L.S.I. 1
IC480 C0ABBA000230 IC 1
Q10,Q180 B1BAAJ000003 TRANSISTOR 2
D25 D4EAY271A036 ZENER RESISTOR 1 270V
RY1 AEBGJQC25F18 POWER RELAY 1
T10 G4C2AAD00006 LOW VOLTAGE TRANSFORMER 1 120V
SW1-SW7,SW10-SW13,SW15-SW17 EVQ11L05R SWITCH 14
RE81 EVEJ1HF2224B REVOLVING ENCODER 1
ZD10 B0BA5R600016 ZENER DIODE 1
ZD180 DZ2J15000L ZENER DIODE 1
10.3.2. NN-SN671S, SN661S, SN651B/W
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ210 L0DDEA000014 BUZZER 1 2.0KHz
C10 F2A1H471B575 AL CHEM CAPACITOR 1 470µF/50V
C11 F2A1C220B624 AL CHEM CAPACITOR 1 22µF/16V
C482 F2A1H1R0B574 AL CHEM CAPACITOR 1 1µF/50V
C483 F2A1HR47B574 AL CHEM CAPACITOR 1 0.47µF/50V
C485 F2A1H2R2B574 AL CHEM CAPACITOR 1 2.2µF/50V
DISP110 L5AYAYY00096 LCD 1
DISP HOLDER F66179Y20AP LCD HOLDER 1
F67525E20XN DIFFUSION SHEET 1
D40,D41,D189,D190,D221,D227,
D228,D230
B0AACK000004 DIODE 8
D10-D13 B0EAKT000025 DIODE 4
IC1 MN69F009AC1 L.S.I. 1
IC480 C0ABBA000230 IC 1
Q10,Q180 B1BAAJ000003 TRANSISTOR 2
D25 D4EAY271A036 ZENER RESISTOR 1 270V
RY1 AEBGJQC25F18 POWER RELAY 1
T10 G4C2AAD00006 LOW VOLTAGE TRANSFORMER 1 120V
ZD10 B0BA5R600016 ZENER DIODE 1
41
NN-SD681S / NN-SN671S / NN-SN661S / NN-SA661S / NN-SA651S / NN-SN651B / NN-SN651W / NN-SA631B / NN-SA631W
