Alignments
EN 72 SDI PDP 2K68.
Figure 8-13 Waveform adjustment (Y-Board) - 42 SD v5
Figure 8-14 Rising ramp waveform (Y-Board) - 42 SD v5
Figure 8-15 Falling ramp flat time adjustment (Y-Board) - 42 SD v5
G_16380_401.eps
160606
XWW}
YWWG
mGG
zGG
<Rising ramp>
The second point is located 100 V
below and 200 sec before the first
point.
G_16380_402.eps
160606
zGG
mGG
\W}G
X]WG
<Falling ramp>
The second point is located 50 Volt
above and 160 usec before the first
point.
