Playing a Tape
1
Press the VCR/TV button to put the VCR in VCR position
(the VCR/TV light will appear).
2
Make sure the Cable Box is on the same channel as the
VCR’s CH3/CH4 switch.
3
Use the TV channel selector to put the TV on the Cable Box
output channel (channel 03 or 04).
4
Press the PLAY button to play the tape.
Hookups With a Cable Box (cont’d) 9
VIDEO
IN
OUT
CH3
CH4
AUDIO
OUT
IN
ANT
IN
OUT
This connection allows you to program an unattended recording of more than one unscram-
bled channel and to watch one channel while recording another. After you connect the VCR,
Cable Box, and TV as shown below, the features on this page will be available.
Recording One Channel/Watching Another
1
With the VCR on and in VCR position (the VCR/TV light will
appear), use the CHANNEL (Up/Down) buttons to select
the channel you want to record. Start the recording.
2
Press the VCR/TV button to put the VCR in TV position.
3
Use the TV channel selector to put the TV on the Cable Box
output channel (channel 03 or 04).
4
Select the channel you want to watch at the Cable Box.
• You cannot record scrambled chan-
nels with this connection.
Helpful Hint
1. Connect a Cable
signal to the VCR’s
ANT(enna) IN Jack.
3. Use a second RF coaxial cable to connect the OUT Jack on
the Cable Box to the Antenna In Jack on the back of the TV.
2. Use an RF coaxial cable (supplied) to connect
the OUT Jack on the VCR to the IN Jack on the
Cable Box.
TV
Antenna
In Jack
CHANGED
INSERT NEW
PAGE
SVZ142.comb 4/7/99 6:30 PM Page 9
