Philips SW200 - PCB Layout View - Combi Board

5-3
5-3
PCB LAYOUT VIEW - COMBI BOARD
C301 G4
C302 G3
C303 B1
C304 A1
C305 B1
C306 B1
C340 C1
C351 B2
C352 B2
C353 C2
C354 C2
C355 C2
C356 C2
C357 C3
C360 B3
C401 A2
C402 A2
C403 B2
C404 B2
C405 B3
C406 B3
C407 A3
C410 B3
C411 A3
C412 B3
C413 B3
C414 B3
C415 A3
C422 A3
C507 A5
C508 A6
C509 A6
C510 B5
C511 B5
C512 B4
C513 C4
C514 B4
C515 A4
C516 B7
C905 C5
C906 C4
C907 C6
C908 C4
C913 C8
C914 C8
C916 B6
C917 B7
C918 B6
C919 B6
CN301 B1
CN351 B8
CN401 B8
CN503 B6
CN906 C8
D351 C2
D352 C2
D504 B7
DB901 C6
F902 C7
F903 C7
IC351 C3
IC401 B3
IC502 A4
JK301 G3
JW351 C3
JW352 C3
JW353 B4
JW355 B4
JW356 B4
JW401 B4
JW501 B4
JW502 B6
JW503 B6
JW505 B7
JW506 B5
JW901 C6
JW902 C4
LD401 G1
Q351 C1
Q352 C2
Q353 B7
R301 G3
R302 G3
R303 G3
R304 A2
R350 B2
R351 C1
R352 B1
R353 C1
R354 C2
R355 C2
R356 C2
R357 C2
R358 B2
R359 C2
R360 B2
R361 B2
R362 B2
R363 C2
R364 C3
R365 C3
R366 C3
R367 C3
R368 C3
R369 C3
R370 B7
R373 B7
R374 B8
R375 B7
R376 B7
R401 A2
R402 A2
R403 B2
R404 B2
R405 B2
R406 B3
R410 B3
R411 A3
R412 A3
R413 B6
R414 A8
R513 A6
R514 A5
R515 A5
R517 B5
R518 B5
R519 B5
R520 B5
R521 B7
R522 A8
R523 B8
R902 B6
R903 B4
RB301 G3
RB401 G2
SW301 G2
ZD351 B3
ZD501 A8
ZD502 A6
ZD901 B7
ZD902 B6
