Philips SW200 - Electrical Parts List - Combi Board

5-45-4
ELECTRICAL PARTS LIST - COMBI BOARD (AMPLIFIER, INPUT, LED & EARPHONE PARTS)
MISCELLANEOUS
CN906 9965 000 12617
!
CONNECTOR 3PIN PITCH=3,96MM
F902 9965 000 14288
!
FUSE T4A 250V SLOW /17/17S
F902 9965 000 16184
!
FUSE T4A 250V SLOW /00S/02S/15S
F903 9965 000 14288
!
FUSE T4A 250V SLOW /17/17S
F903 9965 000 16184
!
FUSE T4A 250V SLOW /00S/02S/15S
JK301 4822 267 41238 JACK 1T GREEN
SW301 4822 277 11821 SLIDE SWITCH
CAPACITORS
C301 4822 122 33293 100PF 5% 50V
C302 4822 124 21913 1UF 20% 63V
C303 4822 124 21913 1UF 20% 63V
C304 9965 000 08286 0,022UF 100V 5%
C305 4822 124 21913 1UF 20% 63V
C306 9965 000 08286 0,022UF 100V 5%
C340 9965 000 12559 100UF 16V 20%
C351 4822 124 22652 2,2UF 20% 50V
C352 2038 554 00065 100NF +80/-20% 50V
C353 9965 000 12614 47PF 50V 5%
C354 9965 000 12522 4,7UF 50V 20%
C355 9965 000 12614 47PF 50V 5%
C356 9965 000 12559 100UF 16V 20%
C357 9965 000 12558 220UF 16V 20%
C360 9965 000 12559 100UF 16V 20%
C401 4822 122 33293 100PF 5% 50V
C402 4822 121 41935 12NF 5% 250V
C403 5322 121 42662 68NF 5% 250V
C404 5322 121 42662 68NF 5% 250V
C405 5322 121 42489 33NF 5% 250V
C406 4822 121 42077 6,8NF 10% 400V
C407 4822 124 22652 2,2UF 20% 50V
C410 4822 124 40433 47UF 20% 25V
C411 4822 124 40433 47UF 20% 25V
C412 4822 122 30103 22NF 80% 63V
C413 9965 000 12613 0,22UF 50V +80/-20%
C414 9965 000 12613 0,22UF 50V +80/-20%
C415 4822 122 30103 22NF 80% 63V
C422 5322 121 42662 68NF 5% 250V
C507 4822 122 33293 100PF 5% 50V
C508 5322 124 41945 22UF 20% 35V
C509 4822 124 40433 47UF 20% 25V
C510 9965 000 12614 47PF 50V 5%
C511 5322 121 42578 100NF 5% 250V
C512 9965 000 12536 100UF 50V 20%
C513 2038 554 00065 100NF +80/-20% 50V
C514 9965 000 12536 100UF 50V 20%
C515 2038 554 00065 100NF +80/-20% 50V
C516 4822 124 40433 47UF 20% 25V
C530 9965 000 11041 0,01UF 500V 20%
C905 9965 000 12619
!
6800UF 50V 20%
C906 9965 000 12619
!
6800UF 50V 20%
C907 2038 554 00065 100NF +80/-20% 50V
C908 2038 554 00065 100NF +80/-20% 50V
C913 9965 000 11041 0,01UF 500V 20%
C914 9965 000 11041 0,01UF 500V 20%
C916 2038 554 00065 100NF +80/-20% 50V
C917 4822 124 40207 100UF 20% 25V
C918 2038 554 00065 100NF +80/-20% 50V
C919 4822 124 40207 100UF 20% 25V
RESISTORS
R301 4822 050 21503 15K 1% 0,6W
R302 4822 050 25602 5K6 1% 0,6W
R303 4822 050 21003 10K 1% 0,6W
R304 4822 050 26202 6K2 1% 0,6W
R340 9965 000 12620 1K8 1/6W 5%
R350 4822 050 24703 47K 1% 0,6W
R351 4822 050 21004 100K 1% 0,6W
R352 4822 050 21004 100K 1% 0,6W
R353 9965 000 09725 4K7 1/6W 5%
R354 9965 000 12621 2K 1/6W 5%
R355 9965 000 12622 2M2 1/6W 5%
R356 4822 050 21003 10K 1% 0,6W
R357 9965 000 12623 82 1/6W 5%
R358 9965 000 12624 270K 1/6W 5%
R359 9965 000 12624 270K 1/6W 5%
R360 4822 050 21003 10K 1% 0,6W
R361 4822 050 21003 10K 1% 0,6W
R362 9965 000 12519 1K 1/6W 5%
R363 9965 000 12625 560K 1/6W 5%
R364 9965 000 08284 220K 1/6W 5%
R365 9965 000 12626 1M 1/6W 5%
R366 9965 000 12627 680K 1/6W 5%
R367 9965 000 12628 82K 1/6W 5%
R368 9965 000 12627 680K 1/6W 5%
R369 4822 050 22203 22K 1% 0,6W
R370 4822 050 21003 10K 1% 0,6W
R371 9965 000 12629 30K 1/6W 5%
R373 9965 000 12620 1K8 1/6W 5%
R374 4822 050 22702 2K7 1% 0,6W
R375 9965 000 13450 910R 5% 1/6W
R376 4822 050 24703 47K 1% 0,6W
R401 9965 000 12631 180K 1/6W 5%
R402 4822 050 21003 10K 1% 0,6W
R403 9965 000 08285 18K 1/6W 5%
R404 4822 050 21504 150K 1% 0,6W
R405 9965 000 09724 3K9 1/6W 5%
R406 9965 000 08285 18K 1/6W 5%
R410 4822 050 21001 100R 1% 0,6W
R411 4822 050 21001 100R 1% 0,6W
R412 9965 000 08285 18K 1/6W 5%
R413 9965 000 09725 4K7 1/6W 5%
R414 9965 000 09725 4K7 1/6W 5%
R513 9965 000 12519 1K 1/6W 5%
R514 4822 050 24703 47K 1% 0,6W
R515 9965 000 12519 1K 1/6W 5%
R517 4822 050 23303 33K 1% 0,6W
R518 4822 050 23303 33K 1% 0,6W
R519 4822 116 81753 4R7 5% 0,5W
R520 4822 050 23303 33K 1% 0,6W
R521 4822 050 21502 1K5 1% 0,6W
R522 4822 116 52291 56K 5% 0,5W
R523 4822 116 52228 680R 5% 0,5W
R902 9965 000 12632 1K 1W 5%
R903 9965 000 12632 1K 1W 5%
DIODES
D351 4822 130 30621 1N4148
D352 4822 130 30621 1N4148
D504 4822 130 31438
!
1N4001G
DB901 4822 130 70035
!
RS402L
LD401 9965 000 14305 3 BDIA GREEN/ORANGE
ZD501 4822 130 34281 BZX79-B15
ZD502 9965 000 12635 ZENER 9,1-9,5V 0,5W
ZD901 4822 130 34281 BZX79-B15
ZD902 4822 130 34281 BZX79-B15
TRANSISTORS & INTEGRATED CIRCUITS
IC351 4822 209 83631 NJM4558DD
IC401 4822 209 32742 TL074IN
IC502 9965 000 12633
!
LM3886T POWER IC
Q351 4822 130 41198 2SC945P
Q352 4822 130 41198 2SC945P
Q353 4822 130 41198 2SC945P
Note: Only the parts mentioned in this list are normal service spare
parts.
ELECTRICAL PARTS LIST - COMBI BOARD (AMPLIFIER, INPUT, LED & EARPHONE PARTS)
