10 EN
1 Drill 2 parallel holes (diameter 3-8mm
each according to wall type) on the
wall.
2 Secure the dowels and screws in the
holes.
3 Hang the soundbar on the fastening
screws.
The distance between the holes
are: 830mm / 32.68”
You can use the wall mount
template provided for helping the
drilling holes position on the wall.
Be sure to leave a 2.5-3.0mm gap
between the wall and the screw’s
head.
1
~50mm/2.0"
830mm / 32.68”
2
2.5-3.0mm/0.1-0.12”
4mm
/
0.16"
>33mm/1.3"
3
4
