Revision List
EN 2 TPN15.2E LA1.
2015-Nov-27
back to
div. table
1. Revision List
Manual xxxx xxx xxxx.0
• First release.
Manual xxxx xxx xxxx.1
• Chapter 2: Updated table 2.1 Technical Specifications
.
• Chapter 5: Updated table 5-2 Factory mode overview
.
• Chapter 6: Updated tables 6-2 White tone default settings
and 6-3 Display code overview
.
Manual xxxx xxx xxxx.2
• Chapter 2: Updated table 2.1 Technical Specifications
.
• Chapter 6: Updated tables 6-2 White tone default settings
and 6-3 Display code overview
.
2. Technical Specs, Diversity, and Connections
Index of this chapter:
2.1 Technical Specifications
2.2 Directions for Use
2.3 Connections
2.4 Chassis Overview
Notes:
• Figures can deviate due to the different set executions.
• Specifications are indicative (subject to change).
2.1 Technical Specifications
For on-line product support please use the links in Table 2-1.
Here is product information available, as well as getting started,
user manuals, frequently asked questions and software &
drivers.
Table 2-1 Described Model Numbers and Diversity
2.2 Directions for Use
Directions for use can be downloaded from the following
websites:
http://www.philips.com/support
http://www.p4c.philips.com
CTN
24 910 11
Connection Overview
Mechanics
Block Diagram
Schematics
Styling Wire Dressing Stand Removal Rear Cover Removal SSB Removal IR/LED Board Removal Power Supply SSB J (IR/LED ) E (Keyboard/Leading Edge)
43PUH4900/88 2-1 4-1 4-4 4-5 4-6 4-7 & 4-8 9.1 10.1 10.3 10.4 10.5 11.1
43PUT4900/12 2-1 4-1 4-4 4-5 4-6 4-7 & 4-8 9.1 10.1 10.3 10.4 10.5 11.1
43PUK4900/12 2-1 4-1 4-4 4-5 4-6 4-7 & 4-8 9.1 10.1 10.3 10.4 10.5 11.1
43PUT4900/60 2-1 4-1 4-4 4-5 4-6 4-7 & 4-8 9.1 10.1 10.3 10.4 10.5 11.1
49PUH4900/88 2-1 4-2 4-4 4-5 4-6 4-7 & 4-8 9.1 10.1 10.3 10.4 10.5 11.2
49PUT4900/12 2-1 4-2 4-4 4-5 4-6 4-7 & 4-8 9.1 10.1 10.3 10.4 10.5 11.2
49PUK4900/12 2-1 4-2 4-4 4-5 4-6 4-7 & 4-8 9.1 10.1 10.3 10.4 10.5 11.2
49PUT4900/60 2-1 4-2 4-4 4-5 4-6 4-7 & 4-8 9.1 10.1 10.3 10.4 10.5 11.2
55PUH4900/88 2-1 4-3 4-4 4-5 4-6 4-7 & 4-8 9.1 10.2 10.3 10.4 10.5 11.3
55PUT4900/12 2-1 4-3 4-4 4-5 4-6 4-7 & 4-8 9.1 10.2 10.3 10.4 10.5 11.3
55PUK4900/12 2-1 4-3 4-4 4-5 4-6 4-7 & 4-8 9.1 10.2 10.3 10.4 10.5 11.3
55PUT4900/60 2-1 4-3 4-4 4-5 4-6 4-7 & 4-8 9.1 10.2 10.3 10.4 10.5 11.3
