109B6 CRT
2
GENERAL PRODUCT SPECIFICATION
Go to cover page
8639 000 15742
BRAND : PHILIPS
V40 109B6 97KHZ
TYPE :109B60/00
2004-08-11
2004-08-11
27
Michael Wang
INDEX
=========
1.0Introduction
2.0 General description
2.1 General condition
3.0Electrical characteristics
3.1 Signal interface
3.1.1Input requirements A. Input signals B. Impedance
3.1.2 Signals input.
3.1.3 Factory pre-setmodes
3.
2Timing requirements
3.2.1Horizontal scanning
3.2.2Vertical scanning
3.3 Power supply
3.4Powersaving managementsystem
3.5 CRT description
3.6RGBamplifier
3.6.1Video amplifier
3.6.2Brightness and contr
ast
3.6.3 sRGB
3.7Variation of image sizeafterwarm-up 30 minutes
3.8Degaussing
3.9Phosphor protection
3.10 Low emission requirements (TCO/MPRII)
3.11 Displaydata channel: DDC2B (VESA STANDARD)
4.0Display
4.1Displayresoluti
on
4.2Image size
4.3 Image centering deviation
4.4Picture shift control range
4.5Geometric distortions
4.6Picture tilt
