Philips VR540/39 - Electrical Parts List; Capacitors List

NOTES:
C…..±0.25% D…..±0.5% F…..±1%
G…..±2% J…..±5% K…..±10%
M…..±20% N…..±30% Z…..+80/-20%
ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
ELECTRICAL PARTS LIST
Consists of the following
MAIN CBA(MCV-A)
111111111
SUB JACK CBA(MCV-B)
1111111
JACK CBA(MCV-C)
111111111
SENSOR CBA
111111111
SUB JACK CBA
1111111
FUNCTION CBA
1111111
AFV CBA
11
MAIN CBA
2B7 9965 000 16617 HEAD SHIELD ASSEMBLY HE470ED
111111111
2B8 9965 000 08566 BUSH, LED(F) H3700UD
111111111
2B46 9965 000 12173 ROHM HOLDER H7770JD
111111111
CAPACITORS
C002
h 9965 000 06521 METALLIZED FILM CAP. 0.068UF/250V K
111111111
C003
h 9965 000 06522 SAFETY CAP. 2200PF/250V
111111111
C004 4822 124 80025 ELECTROLYTIC CAP. 33UF/400V M(L?Z)
111111111
C005 4822 126 14142 CERAMIC CAP. B K 0.01UF/500V
111111111
C006 4822 126 14141 CERAMIC CAP. SL K 56PF/1KV
111111111
C007 CERAMIC CAP.(AX) B K 1000PF/50V
111111111
C008 CERAMIC CAP.(AX) X K 5600PF/16V
111111111
C010 FILM CAP.(P) 0.022UF/50V J
111111111
C011 ELECTROLYTIC CAP. 10UF/16V M H7
111111111
C012 ELECTROLYTIC CAP. 10UF/50V M H7
111111111
C014 ELECTROLYTIC CAP. 470UF/35V M
111111111
C017 ELECTROLYTIC CAP. 470UF/16V M
111111111
C018 ELECTROLYTIC CAP. 100UF/16V M
111111111
C020 ELECTROLYTIC CAP. 1000UF/16V M
111111111
C021 ELECTROLYTIC CAP. 470UF/10V M
111111111
C025 CERAMIC CAP.(AX) X K 5600PF/16V
111111111
C026 ELECTROLYTIC CAP. 47UF/16V M H7
111111111
C053 ELECTROLYTIC CAP. 330UF/6.3V M
111111111
C056 CHIP CERAMIC CAP. B K 0.047UF/25V
111111111
C057 CHIP CERAMIC CAP. CG J 470PF/50V
111111111
C060 ELECTROLYTIC CAP. 10UF/16V M H7
111111111
C061 CHIP CERAMIC CAP. F Z 0.1UF/25V
111111111
C157 ELECTROLYTIC CAP. 1UF/50V M H7
111111111
C158 CHIP CERAMIC CAP. B K 1000PF/50V
111111111
C251 ELECTROLYTIC CAP. 10UF/16V M H7
111111111
C252 CHIP CERAMIC CAP. B K 1000PF/50V
111111111
C253 ELECTROLYTIC CAP. 1UF/50V M H7
111111111
C254 CHIP CERAMIC CAP. F Z 0.1UF/25V
111111111
C302 CHIP CERAMIC CAP. B K 0.022UF/25V
111111111
