Philips VR540/39 - Mechanical Parts List

MECHANICAL PARTS LIST
Pos. h 12 NC Description
A1X 9965 000 17133 FRONT ASSEMBLY HE473FD
1
A1X 9965 000 16680 FRONT ASSEMBLY HE471BD
1
A1X 9965 000 17163 FRONT ASSEMBLY HE480ED
1
A1X 9965 000 17141 FRONT ASSEMBLY HE481BD
1
A1X 9965 000 17152 FRONT ASSEMBLY HE482ED
11
A1X 9965 000 17154 FRONT ASSEMBLY HE486ED
11
A1X 9965 000 17159 FRONT ASSEMBLY HE487FD
1
A2 9965 000 16612 CASE, TOP HE470ED
11
A2 9965 000 17142 CASE, TOP(U27 FTZ 435) HE480ED
1111
A2 9965 000 17155 CASE, TOP(BLACK) HE485BD
111
A3 9965 000 16613 CHASSIS HE470ED
11
A3 9965 000 17143 CHASSIS(U27 FTZ 435MM) HE480ED
1111
A3 9965 000 17156 CHASSIS(BLACK) HE485BD
111
A7 9965 000 16614 PANEL, BOTTOM HE470ED
11
A7 9965 000 17144 PANEL, BOTTOM(435MM) HE480ED
1111111
A29 CHASSIS FOOT H79P9JD
111111111
1B1 DECK ASSEMBLY CZD012/VM17E0
111111111
2B5 9965 000 12168 SHEILD, CYLINDER HC460ED
111111111
2L011 9965 000 16615 SCREW, P-TIGHT 3X10 BIND HEAD+
111111
2L011 4822 502 14666 SCREW, P-TIGHT 3X10 BIND HEAD+
111
2L012 9965 000 16615 SCREW, P-TIGHT 3X10 BIND HEAD+
111111
2L012 4822 502 14666 SCREW, P-TIGHT 3X10 BIND HEAD+
111
2L021 4822 502 30752 SCREW, P-TIGHT M3X10 WASHER HEAD+
111111111
2L031 4822 502 14009 SCREW, S-TIGHT M3X6 BIND HEAD+
111111111
2L041 4822 502 14012 P-TIGHT SCREW 3X8 BIND +
111111111
2L042 4822 502 14012 P-TIGHT SCREW 3X8 BIND +
111111111
2L043 4822 502 14012 P-TIGHT SCREW 3X8 BIND +
1111111
2L051 4822 502 14018 SCREW, S-TIGHT M3X5 BIND HEAD+
111111111
2L099 9965 000 13027 SCREW, P-TIGHT M3X8 BIND HEAD+
111111111
PACKING
X1 9965 000 16616 REMOTE CONTROL UNIT 364/CRC007
11
X1 9965 000 17145 REMOTE CONTROL UNIT 364/CRC007
1111
X1 9965 000 17157 REMOTE CONTROL UNIT 364/CRC007
111
X3 9965 000 17134 RF CABLE CC1001020012010
111111111
X3 4822 320 50377 RF CORD PAL 1.2M
111111111
X4 ACCESSORY BAG K8092BA
111111111
X6 9965 000 17135 21P SCART CABLE SD-0799(SG-D91050)
11
PRODUCT SAFETY NOTE: Products marked with a h
have special characteristics important to safety.
Before replacing any of these components, read carefully
the product safety notice in this service manual.
Don’t degrade the safety of the product through improper
servicing.
VR540/39 VR540/58 VR740/02 VR742/39 VR740/58 VR740/07 VR740/16 VR740/58 VR742/16
1-18-2
