ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR540/39 VR742/39 VR540/58 VR740/16 VR742/16 VR740/02 VR740/58 VR740/07 VR740/58
C522 ELECTROLYTIC CAP. 22UF/6.3V M H7
111111111
C523 CHIP CERAMIC CAP. B K 1000PF/50V
111111111
C524 CHIP CERAMIC CAP. CG J 330PF/50V
111111111
C526 CHIP CERAMIC CAP. B K 4700PF/50V
111111111
C527 ELECTROLYTIC CAP. 22UF/6.3V M H7
111111111
C529 CERAMIC CAP.(AX) Y M 0.01UF/16V
111111111
C530 CERAMIC CAP.(AX) F Z 0.022UF/25V
111111111
C531 CERAMIC CAP.(AX) Y M 0.01UF/16V
111111111
C532 ELECTROLYTIC CAP. 22UF/6.3V M H7
111111111
C533 CHIP CERAMIC CAP. F Z 0.1UF/25V
111111111
C535 CHIP CERAMIC CAP. B K 0.01UF/50V
111111111
C538 CHIP CERAMIC CAP. B K 0.022UF/25V
111111111
C540 ELECTROLYTIC CAP. 470UF/6.3V M
111111111
C561 CHIP CERAMIC CAP. B K 0.022UF/25V
111111111
C562 ELECTROLYTIC CAP. 330UF/6.3V M H7
111111111
C564 CHIP CERAMIC CAP. CG J 100PF/50V
111111111
C640 CHIP CERAMIC CAP. F Z 0.1UF/25V
1111111
C642 SEMICONDUCTOR CAP. SR K 0.018UF/25V
1111111
C643 ELECTROLYTIC CAP. 4.7UF/25V M H7
1111111
C644 ELECTROLYTIC CAP. 47UF/6.3V M H7
1111111
C645 CHIP CERAMIC CAP. B K 0.01UF/50V
1111111
C648 ELECTROLYTIC CAP. 1UF/50V M H7
1111111
C649 ELECTROLYTIC CAP. 1UF/50V M H7 NP
1111111
C701 CHIP CERAMIC CAP. B K 0.047UF/25V
111111 1
C702 CHIP CERAMIC CAP. F Z 0.1UF/25V
111111111
C703 ELECTROLYTIC CAP. 10UF/16V M H7
111111111
C704 CHIP CERAMIC CAP. B K 0.01UF/50V
111111111
C706 CHIP CERAMIC CAP. B K 1000PF/50V
111111111
C707 ELECTROLYTIC CAP. 100UF/6.3V H7
111111111
C708 CHIP CERAMIC CAP. B K 0.01UF/50V
111111111
C716 CHIP CERAMIC CAP. F Z 0.22UF/16V
111111111
C717 CHIP CERAMIC CAP. F Z 0.22UF/16V
111111111
C771 CHIP CERAMIC CAP. F Z 0.1UF/25V
111111111
C772 ELECTROLYTIC CAP. 10UF/16V M H7
111111111
C773 CHIP CERAMIC CAP. B K 1000PF/50V
111111111
C774 CHIP CERAMIC CAP. B K 1000PF/50V
111111111
C775 ELECTROLYTIC CAP. 1UF/50V M H7
111111111
C776 ELECTROLYTIC CAP. 1UF/50V M H7
111111111
C777 CHIP CERAMIC CAP. CG J 180PF/50V
111111111
C778 CHIP CERAMIC CAP. CG J 180PF/50V
111111111
C851 CHIP CERAMIC CAP. CG J 22PF/50V
111111111
C852 CHIP CERAMIC CAP. CG J 22PF/50V
111111111
C853 CHIP CERAMIC CAP. B K 4700PF/50V
111111111
C854 CHIP CERAMIC CAP. B K 0.01UF/50V
111111111
C855 CHIP CERAMIC CAP. F Z 0.1UF/25V
111111111
C856 CHIP CERAMIC CAP. CG J 180PF/50V
111111111
C858 CHIP CERAMIC CAP. CG J 560PF/50V
11 1 11
C859 ELECTROLYTIC CAP. 47UF/6.3V M H7
111111111
C862 CHIP CERAMIC CAP. B K 0.01UF/50V
111111111
CN505 9965 000 17146 FNT PCB ASSEMBLY CP2700/E480/FUNCTION
1111111
CN701 9965 000 12254 AFV PCB ASSEMBLY CP2500/C463
11
CN701 9965 000 12175 AFV PCB ASSEMBLY CP2500/C461
1 1111 1
CN701 9965 000 12272 AFV PCB ASSEMBLY CP2500/C460
1
DIODES
D001 4822 130 31933 RECTIFIER DIODE 1N4005
111111111
D002 4822 130 31933 RECTIFIER DIODE 1N4005
111111111
D003 4822 130 31933 RECTIFIER DIODE 1N4005
111111111
D004 4822 130 31933 RECTIFIER DIODE 1N4005
111111111
D005 4822 130 81244 RECTIFIER DIODE ERA22-10
111111111
D006 4822 130 30621 SWITCHING DIODE 1N4148M
111111111
D007 4822 130 30621 SWITCHING DIODE 1N4148M
111111111
D008 4822 130 30621 SWITCHING DIODE 1N4148M
111111111
D009 4822 130 30621 SWITCHING DIODE 1N4148M
111111111
D011 4822 130 41487 RECTIFIER DIODE BA157
111111111
1-16-12
