ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR540/39 VR742/39 VR540/58 VR740/16 VR742/16 VR740/02 VR740/58 VR740/07 VR740/58
MISCELLANEOUS
A4 9965 000 17148 JACK BOARD(U27 FTZ) HE480ED
1111111
AC001
h 9965 000 08666 AC CORD PE8B2CB1H0A-057
111 11111
AC001
h 9965 000 17149 AC CORD PE8B2V51H0A-05B
1
AC001
h 9965 000 12174 AC CORD PQ8B1V51H0A-05B
1
F001
h 9965 000 13786 FUSE 21301.6M
111111111
FH001 4822 256 10461 FUSE HOLDER MSF-015
111111111
FH002 4822 256 10461 FUSE HOLDER MSF-015
111111111
FP562 9965 000 09307 LED DISPLAY LFU-4421-2001A
111111111
J902 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3
111111111
JW001 9965 000 13795 FLAT CABLE, 11P AWG26#2651/P1.25/150
111111111
JW002 9965 000 13796 FLAT CABLE, 12P AWG26#2651/P1.25/150
111111111
PS503 9965 000 12189 PHOTO INTERRUPTER RPI-302C70
111111111
SA001
h 9965 000 08602 SURGE ABSORBER CNR-10D471K
111111111
T001
h 9965 000 16627 SWITCHING TRANSFORMER CSA-SW0233A
111111111
TP301 PCB JUMPER D0.6-P10.0
111111111
TP501 PCB JUMPER D0.6-P6.0
111111111
TP502 PCB JUMPER D0.6-P5.0
111111111
TP506 PCB JUMPER D0.6-P5.0
111111111
TP507 PCB JUMPER D0.6-P6.0
111111111
TU701 9965 000 12256 TUNER UNIT TMDZ2-731A
11
TU701 9965 000 13033 TUNER UNIT TMDG2-731A
111
TU701 9965 000 12265 TUNER UNIT TMDG2-631A
111
TU701 9965 000 12193 TUNER UNIT TMDG2-632A
1
VR501 9965 000 05260 CARBON P.O.T. 100K OHM B
111111111
X301 9965 000 05629 X’TAL 4.433619MHZ
111111111
X501 9965 000 12194 X’TAL 12.000MHZ
111111111
X502 9965 000 12288 X’TAL 32.768KHZ(20PPM)
111111111
SUB JACK CBA
C751 CHIP CERAMIC CAP. B K 2200PF/50V
1111111
C752 CHIP CERAMIC CAP. B K 2200PF/50V
1111111
R751 CHIP RES.(1608) 1/10W J 820 OHM
1111111
R752 CHIP RES.(1608) 1/10W J 820 OHM
1111111
JK751 9965 000 13039 RCA JACK MSP-282V-12 PBSN
1111111
JW004 9965 000 17150 FLAT CABLE, 3P AWG26#2651/P1.25/200
1111111
JACK CBA
A5 9965 000 16629 JACK BOARD(2-21P) HE470ED
11
A5 9965 000 17151 JACK BOARD(2-21P) HE480ED
1111
A5 9965 000 17158 JACK BOARD 21P,BLACK HE485BD
111
CAPACITORS
C101 CHIP CERAMIC CAP. B K 2200PF/50V
111111111
C102 CHIP CERAMIC CAP. B K 2200PF/50V
111111111
C103 CHIP CERAMIC CAP. CG J 470PF/50V
111111111
C104 CHIP CERAMIC CAP. CG J 470PF/50V
111111111
C105 CHIP CERAMIC CAP. F Z 0.1UF/25V
111111111
C107 ELECTROLYTIC CAP. 1UF/50V M H7
111111111
C108 CHIP CERAMIC CAP. B K 1000PF/50V
111111111
C109 CHIP CERAMIC CAP. B K 2200PF/50V
111111111
C110 CHIP CERAMIC CAP. B K 2200PF/50V
111111111
C111 CHIP CERAMIC CAP. CG J 470PF/50V
111111111
C112 CHIP CERAMIC CAP. CG J 470PF/50V
111111111
C113 CHIP CERAMIC CAP. B K 2200PF/50V
111111111
C115 ELECTROLYTIC CAP. 100UF/16V M H7
111111111
C116 ELECTROLYTIC CAP. 470UF/6.3V M
111111111
C117 ELECTROLYTIC CAP. 470UF/6.3V M
111111111
DIODES
D101 9965 000 12178 ZENER DIODE DZ-11BSAT265
111111111
D102 9965 000 12178 ZENER DIODE DZ-11BSAT265
111111111
D103 9965 000 12178 ZENER DIODE DZ-11BSAT265
111111111
D104 9965 000 12178 ZENER DIODE DZ-11BSAT265
111111111
D105 9965 000 12178 ZENER DIODE DZ-11BSAT265
111111111
D106 9965 000 12177 ZENER DIODE DZ-6.8BSCT265
111111111
COILS
L101 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3
111111111
