Philips VR540/39 - Page 53

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR540/39 VR742/39 VR540/58 VR740/16 VR742/16 VR740/02 VR740/58 VR740/07 VR740/58
CN1 4822 265 11267 ANGLE PIN HEADER, 9P 6029B-1-09Z003-T
111111111
DIODES
D2 4822 130 30621 SWITCHING DIODE 1N4148M
111111111
IC’s
IC1 9965 000 14760 IC:AUDIO PROCESSOR MSP3417G-QG-B8
11 111111
IC1 9965 000 14760 IC:AUDIO PROCESSOR MSP3417G-QG-B8-V3
11 111111
IC1 9965 000 12274 IC:AUDIO PROCESSOR MSP3407G-QG-B8
1
IC1 9965 000 17164 IC:AUDIO PROCESSOR MSP3407G-QG-B8-V3
1
COILS
L1 4822 157 10889 INDUCTOR 10UH-K-26T
111111111
L2 PCB JUMPER D0.6-P5.0
111111111
L3 4822 157 11318 INDUCTOR 18UH-K-26T
111111111
L4 4822 157 10889 INDUCTOR 10UH-K-26T
111111111
RESISTORS
R1 9965 000 13036 CHIP RES.(1608) 1/10W J 1K OHM
111111111
R2 9965 000 09942 CHIP RES.(1608) 1/10W 0 OHM
11
R4 9965 000 13037 CHIP RES.(1608) 1/10W J 120K OHM
111111111
R5 9965 000 09942 CHIP RES.(1608) 1/10W 0 OHM
111111111
R6 9965 000 09942 CHIP RES.(1608) 1/10W 0 OHM
111111111
R7 CHIP RES.(1608) 1/10W J 1.2K OHM
11
X1 9965 000 12200 X’TAL 18.432MHZ
111111111
1-16-20
