Technical data
108997_en_04 PHOENIX CONTACT 161 / 226
Conductor cross section flexible min. 0.2 mm²
Conductor cross section flexible max. 2.5 mm²
Conductor cross section AWG min. 24
Conductor cross section AWG max. 16
Stripping length 10 mm
Connection data
Interface: Ethernet (RJ45)
Number of interfaces 4
Connection method RJ45
Note on the connection method Auto negotiation and autocrossing
Transmission physics Copper
Transmission speed 10/100 Mbps
Transmission length 100 m (per segment)
Interface: SFP module
Number of interfaces 2
Connection method SFP ports
Transmission physics Depending on the SFP module
Transmission speed 100 Mbps (full duplex)
Transmission length up to 40 km (depending on the SFP module used)
Interface: Ethernet (combo)
Number of interfaces 2
Connection method SFP or RJ45 ports
Note on the connection method Auto negotiation and autocrossing
Transmission physics Depending on the SFP module
Transmission speed 10/100 Mbps (full duplex)
Transmission length up to 40 km (Depending on the fiber/SFP module used)
Supply voltage
Supply voltage 24 VDC (redundant)
Residual ripple 3.6 V
PP
(within the permitted voltage range)
Supply voltage range 19.2 VDC ... 32 VDC
Typical current consumption 200 mA (at U
S
= 24VDC and 25°C ambient temperature)
Max. current consumption 290 mA (U
S
= min, T
amb
= max)
Maximum power dissipation for nominal condition 5.44 W (U
S
= max, T
amb
= max)
Test section for one minute 500 VDC
