Technical data
108997_en_04 PHOENIX CONTACT 63 / 226
Conductor cross section AWG min. 24
Conductor cross section AWG max. 16
Stripping length 9 mm
Connection data
Interface: Ethernet (RJ45)
Number of interfaces 5
Connection method RJ45
Note on the connection method Auto negotiation and autocrossing
Transmission physics Copper
Transmission speed 10/100/1000 Mbps
Transmission length 100 m (per segment)
Supply voltage
Supply voltage 24 VDC (single)
Residual ripple 3.6 V
PP
(within the permitted voltage range)
Supply voltage range 18 VDC ... 32 VDC
Typical current consumption 225 mA (at U
S
= 24VDC and 25°C ambient temperature)
Max. current consumption 0.35 A (At U
S
= 18 V DC and 60°C ambient temperature)
Maximum power dissipation for nominal condition 6.12 W (At U
S
= 18 V DC and 60°C ambient temperature)
Test section for one minute 500 VDC
Mechanical tests
Mechanical tests Free fall in accordance with EN61131-2
Vibration (operation) 2g, according to IEC60068-2-6
Vibration (storage/transport) 2g, criterion 1 according to IEC 60068-2-6
Shock (operation) 30g (EN60068-2-27)
Conformity with EMC directives
Electromagnetic compatibility Conformance with EMC Directive 2014/30/EU
Conducted noise emission EN 61000-6-2 EN 61000-6-4 (conducted interference) Class A
Interference emission EN 61000-6-2 EN 61000-6-4 (interference) Class A
Immunity to burst EN 61000-6-2 EN 61000-4-4 (EFT burst) Criterion A
Immunity to EF EN 61000-6-2 EN 61000-4-3 (electromagnetic fields) Criterion
A
Immunity to ESD EN 61000-6-2 EN 61000-4-2 (ESD) Criterion B
Immunity to surge EN 61000-6-2 EN 61000-4-5 (surge) Criterion A
Immunity to conducted interference EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A
Approvals / Certificates
UL, USA UL 61010-1, Ed.3 / UL 61010-2-201, Ed.1
UL, Canada CSA C22.2 NO.61010-2-201:14, Ed.1 / CSA C22.2 NO.61010-
1-12, Ed.3
Further approvals cULus Listed, EAC, CC-Link IE Field
