Phoenix Contact FL WLAN 2100 User Manual

Technical data
107390_en_03 PHOENIX CONTACT 47
6 Technical data
General data
Function WLAN access point/client/repeater, 2.4 GHz, 5 GHz, internal MIMO antennas
Housing dimensions (width x height x depth) in mm
Outside dimensions, without mounting brackets 62.8 mm x 36.5 mm x 113.2 mm
Permissible operating temperature 0°C to 60°C (FL WLAN 110x)
-40°C to 60°C (FL WLAN 210x)
Permissible storage temperature 0°C to 70°C (FL WLAN 110x)
-40°C to 85°C (FL WLAN 210x)
Degree of protection
not assessed in compliance with UL, assessed by PTL
IP54 for FL WLAN 110x
IP65/66/67/68 for FL WLAN 210x IEC 60529
Humidity
Operation 5% to 95%, non-condensing
Storage 5% to 95%, non-condensing
Air pressure
Operation 800 hPa to 1080 hPa, up to 2000 m above sea level
Storage 660 hPa to 1080 hPa, up to 3500 m above sea level
Mounting position Any
Connection to protective ground By means of lower housing part or additional screw connection
Configuration Web-based management via http or https, SNMPv2/v3, CLI via Telnet/SSH,
password-protected
Pollution degree 2
Overvoltage category None
Weight 340 g
Impact strength IK08
Absence of substances that would hinder coating with paint or varnish Solvent test according to specification 3.10.7
DOWNLOADED FROM WWW.SCATTS.CO.UK
DOWNLOADED FROM WWW.SCATTS.CO.UK

Phoenix Contact FL WLAN 2100 Specifications

General

Model	FL WLAN 2100
Wireless Standard	IEEE 802.11a/b/g/n
Max Data Rate	300 Mbps
Protection Class	IP20
Frequency Band	2.4 GHz
Antenna Connection	RP-SMA
Configuration	Web-based
Security	WPA2
Operating Voltage	24 V DC (12 V DC ... 48 V DC)
